Yamaha XV 1900 Stratoliner Deluxe (2010-11) technical specifications

Yamaha XV 1900 Stratoliner Deluxe technical specifications

Yamaha XV 1900 Stratoliner Deluxe is produced in 2010-11. Engine is Four stroke, pushrod 48° V-Twin, OHV, 2 valves per cylinder, displacement 1854 cc / 113 cu-in , produces power 98.6 hp / 72.0 kW) @ 4250 rpm and 166.7 Nm / / 17 kg-m / 123 ft-lb @ 2250 rpm. Yamaha XV 1900 Stratoliner Deluxe wet weight is 368 kg / 810 lb. Yamaha XV 1900 Stratoliner Deluxe has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: XV 1900 Stratoliner Deluxe
Years: 2010-11
Engine: Four stroke, pushrod 48° V-Twin, OHV, 2 valves per cylinder
Capacity: 1854 cc / 113 cu-in
Bore x Stroke: 100 х 118 mm
Cooling System: Air cooled
Compression Ratio: 9.5:1
Lubrication: Dry sump
Induction: Twin-bore electronic fuel injection, 43mm throttle bodies and throttle position sensor
Ignition: Digital TCI
Starting: Electric
Max Power: 98.6 hp / 72.0 kW) @ 4250 rpm
Max Torque: 166.7 Nm / / 17 kg-m / 123 ft-lb @ 2250 rpm
Clutch: Wet, multiple disc
Transmission: 5 Speed
Final Drive: Belt
Front Suspension: 46mm telescopic forks, adjustable preload
Front Wheel Travel: 134.5 mm / 5.3 in
Rear Suspension: Single shock, link-type
Rear Wheel Travel: 109 mm / 4.3 in
Front Brakes: 2x 298mm discs 4 piston calipers
Rear Brakes: Single 320mm disc 4 piston caliper
Front Tyre: 130/70 R -18
Rear Tyre: 190/60 R-17
Rake: 31°
Trail: 152 mm / 6.0 in
Dimensions: Length 2580 mm / 101.6 in Width 1055m / 41.5 in Height 1515 mm / 59.6 in
Wheelbase: 1715 mm / 67.5 in
Seat Height: 705 mm / 27.8 in
Wet Weight: 368 kg / 810 lb
Fuel Capacity: 17 Litres / 4.4 US gal
