Yamaha XT660R (2010) technical specifications

Yamaha XT660R technical specifications

Yamaha XT660R is produced in 2010. Engine is Four stroke, single cylinder, SOHC, 4 valve, displacement 659 cc/ 40.2 cu-in , produces power 33.8 kW / 48 hp @ 6000 rpm and 58.4 Nm / 5.7 kgf-m @ 5250 rpm. Yamaha XT660R top speed is 164.7 km/h / 102.3 mph. Yamaha XT660R wet weight is 181 kg / 421 lbs. Yamaha XT660R has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: XT660R
Years: 2010
Engine: Four stroke, single cylinder, SOHC, 4 valve
Capacity: 659 cc/ 40.2 cu-in
Bore x Stroke: 100 x 84 mm
Compression Ratio: 10.0: 1
Cooling System: Liquid cooled
Induction: Fuel injection, 44 mm throttle body
Lubrication: Dry sump
Oil Capacity: 2.9 Litres / 0.19 quarts
Ignition: TCI
Starting: Electric
Max Power: 33.8 kW / 48 hp @ 6000 rpm
Max Torque: 58.4 Nm / 5.7 kgf-m @ 5250 rpm
Clutch: Wet, multiple-disc coil spring
Transmission: 5 Speed
Final Drive: Chain
Frame: Steel tubular diamond frame with dual tank rails
Front Suspension: 43 mm Telescopic forks,
Front Wheel Travel: 225 mm / 8.8 in
Rear Suspension: Oscillating arm standard Monocross. 200mm wheel travel
Rear Wheel Travel: 200 mm / 7.9 in
Front Brakes: Single 298mm disc 2 piston caliper
Rear Brakes: Single 245mm disc 1 piston caliper
Front Tyre: 90/90- 21
Rear Tyre: 130/80–17
Rake: 27.0°
Trail: 107 mm / 4.2 in
Dimensions: Height 1230 mm / 48.4 in Length 2240 mm / 88.1 in Width 845 mm / 33.2 in
Wheelbase: 1505 mm / 59.3 in
Ground Clearance: 210 mm / 8.3 in
Seat Height: 865mm / 34.1 in
Dry Wight: 172 kg / 379.2 lbs
Wet Weight: 181 kg / 421 lbs
Fuel Capacity: 15 Litres / 3.3 US gal
Consumption Average: 23 km/lit
Standing ¼ Mile: 14.2 sec
Top Speed: 164.7 km/h / 102.3 mph
