Yamaha XT 660X (2011) technical specifications

Yamaha XT 660X technical specifications

Yamaha XT 660X is produced in 2011. Engine is Four stroke, single cylinder, SOHC, 4 valve, displacement 659 cc/ 40.2 cu-in , produces power 33.8 kW / 48 hp @ 6000 rpm and 58.4 Nm / 5.7 kgf-m @ 5250 rpm. Yamaha XT 660X weighs 173 kg / 318.4 lbs. Yamaha XT 660X has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: XT 660X
Years: 2011
Engine: Four stroke, single cylinder, SOHC, 4 valve
Capacity: 659 cc/ 40.2 cu-in
Bore x Stroke: 100 x 84 mm
Compression Ratio: 10: 1
Cooling System: Liquid cooled
Induction: Fuel injection, 44 mm throttle body
Lubrication: Dry sump
Oil Capacity: 2.9 Litres / 0.19 quarts
Ignition: TCI
Starting: Electric
Max Power: 33.8 kW / 48 hp @ 6000 rpm
Max Torque: 58.4 Nm / 5.7 kgf-m @ 5250 rpm
Clutch: Wet, multiple-disc coil spring
Transmission: 5 Speed
Final Drive: Chain
Frame: Steel tubular diamond frame with dual tank rails
Front Suspension: 43 mm Telescopic forks,
Front Wheel Travel: 225 mm / 8.8 in
Rear Suspension: Oscillating arm standard Monocross.
Rear Wheel Travel: 200 mm / 7.9 in
Front Brakes: Single 320mm disc 4 piston caliper
Rear Brakes: Single 245mm disc 1 piston caliper
Front Tyre: 120/700-17
Rear Tyre: 160/60-17
Rake: 26.0°
Trail: 94 mm / 3.7 in
Dimensions: Height 1170 mm / 461 in Length 2175 mm / 85.6 in Width: 860 mm / 33.9 in
Wheelbase: 1505 mm / 59.3 in
Ground Clearance: 210 mm / 8.3 in
Seat Height: 875mm / 34.4 in
Dry Weight: 173 kg / 318.4 lbs
Wet Weight: 186 kg / 410.1 lbs
Fuel Capacity: 15 Litres / 3.9 gal
