Yamaha FZR 1000 EXUP (1989) technical specifications

Yamaha FZR 1000 EXUP technical specifications

Yamaha FZR 1000 EXUP is produced in 1989. Engine is Four stroke, 35° forward inclined transverse four cylinder, DOHC, 5 valves per cylinder, displacement 1002 cc / 61.2 cu/in , produces power 145 hp / 105.7 kW @ 10000 rpm and 10.9 kgf-m / 107 Nm @ 8500 rpm. Yamaha FZR 1000 EXUP top speed is 273.4 km/h / 169.8 mph. Yamaha FZR 1000 EXUP weighs 209l kg / 460 lbs. Yamaha FZR 1000 EXUP has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: FZR 1000 EXUP
Years: 1989
Engine: Four stroke, 35° forward inclined transverse four cylinder, DOHC, 5 valves per cylinder
Capacity: 1002 cc / 61.2 cu/in
Bore x Stroke: 75.5 x 56 mm
Cooling System: Liquid cooled
Compression Ratio: 12.0:1
Compression Pressure: 14kg/cm2 (1400kPa, 199 psi)
Compression Range: 13.6kg/cm2 (1360kPa, 194psi) minimum 14.8kg/cm2 (1480kPa, 210psi) maximum
Lubrication: Wet sump
Exhaust: EXUP exhaust control system
Induction: 4x 38mm Mikuni BDST carburetors
Ignition: TCI digital ignition
Battery: YB14L 12V 14AH
Starting: Electric
Max Power: 145 hp / 105.7 kW @ 10000 rpm
Max Power Rear Tyre: 131.7 hp @ 10500 rpm
Max Torque: 10.9 kgf-m / 107 Nm @ 8500 rpm
Clutch: Wet, multi-disc
Transmission: 5 Speed
Final Drive: Chain 532ZLV, 110 Links
Secondary Reduction Ratio: 68/41 (1.659)
Frame: Diamond Deltabox
Front Suspension: 43mm Telehydraulic for adjustable preload
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Gas/oil single shock, rising rate adjustable preload and damping
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2x 320mm discs 4 piston calipers
Rear Brakes: Single 267mm disc 1 piston caliper
Front Tyre: 130/60 VR17
Rear Tyre: 170/60 VR17
Rake: 26.7°
Trail: 110mm / 4.33 in
Dimensions: Length 2200 mm / 86.8 in Width 730 mm / 28.7 in Height 1160 mm / 45.7 in
Wheelbase: 1460 mm / 57.5 in
Seat Height: 765 mm / 30.1 in
Ground Clearance: 135 mm / 5.3 in
Dry Weight: 209l kg / 460 lbs
Wet Weight: 236 kg / 520 lbs
Fuel Capacity: 19 Litres / 4.2 gal
Consumption Average: 16.3 km/lit
Braking 60 - 0 / 100 - 0: 13.1 m / 37.0m
Standing ¼ Mile: 10.1 sec / 216.8 km/h
Top Speed: 273.4 km/h / 169.8 mph
Road Test: Motosprint Superbike Group Test 1991
