Triumph Thruxton 1200R (2016) technical specifications

Triumph Thruxton 1200R is produced in 2016. Engine is Four stroke, 270° crank angle parallel-Twin, SOHC. 4 valve per cylinder., displacement 1200 cc / 73.2 cu-in , produces power 71.5 kW / 96 hp @ 6750 rpm and 111.9 Nm / 11.4 kgf-m / 82.6 lb-ft. @ 4950 rpm. Triumph Thruxton 1200R weighs 203.2 kg / 448 lbs. Triumph Thruxton 1200R has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Thruxton 1200R
Years:	2016
Engine:	Four stroke, 270° crank angle parallel-Twin, SOHC. 4 valve per cylinder.
Capacity:	1200 cc / 73.2 cu-in
Bore x Stroke:	97.6 x 80 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.0:1
Emissions:	EURO 4 Compliant, CO2 – 106.0 g/km
Exhaust:	Brushed stainless steel 2 into 2 exhaust system with twin silencers
Induction:	Multipoint sequential electronic fuel injection
Ignition:	Digital electronic
Starting:	Electric
Max Power:	71.5 kW / 96 hp @ 6750 rpm
Max Torque:	111.9 Nm / 11.4 kgf-m / 82.6 lb-ft. @ 4950 rpm
Clutch:	Wet, multi-plate assist clutch
Transmission:	6 Speed
Final Drive:	Chain, X-ring
Frame:	Tubular steel cradle, Twin-sided, aluminum swingarm – Clear anodized
Front Suspension:	Showa 43mm USD big piston forks, fully adjustable
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Fully adjustable Öhlins twin shocks with piggy back reservoir
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2 x 310mm Floating discs, Brembo 4-piston radial monobloc calipers, ABS
Rear Brakes:	Single 220 mm disc, 2-piston axial floating caliper, ABS
Front Wheel:	32-spoke 17 x 3.5in
Rear Wheel:	32-spoke 17 x 5in
Front Tyre:	120/70 ZR17 – Pirelli Diablo Rosso Corsa
Rear Tyre:	160/60 ZR17 – Pirelli Diablo Rosso Corsa
Rake:	22.8º
Trail:	90.8 mm / 3.57 in
Dimensions:	Length 2105 mm / 82.9 in Width 745 mm / 29.3 in Height 1030 mm / 40.6 in without mirrors
Wheelbase:	1415 mm / 55.7 in
Seat Height:	810 mm / 31.9 in
Dry Weight:	203.2 kg / 448 lbs
Fuel Capacity:	12.5 Litres / 3.8 US Gal / 2.7 Imp gal
