Triumph Street Triple (2016) technical specifications
Triumph Street Triple is produced in 2016. Engine is Liquid-cooled, four stroke, in-line 3-cylinder, DOHC, 12 valves, displacement 675 cc / 41.2 cub in. , produces power 78 kW / 106 hp @ 11850 rpm and 68 Nm / 6.9 kgf-m / 50 ft/lb @ 9750 rpm. Triumph Street Triple top speed is 223.1 km/h / 138.6 mph. Triumph Street Triple weighs 168 kg / 370 lbs. Triumph Street Triple has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Street Triple |
| Years: | 2016 |
| Engine: | Liquid-cooled, four stroke, in-line 3-cylinder, DOHC, 12 valves |
| Capacity: | 675 cc / 41.2 cub in. |
| Bore x Stroke: | 74 x 52.3 mm |
| Compression Ratio: | 12.65:1 |
| Induction: | Multipoint sequential electronic fuel injection with SAI |
| Oil Capacity: | 3.4 Litres / 3.6 US qt / 3.0 Imp qt |
| Exhaust: | Stainless steel 3 into 1 exhaust system low single sided stainless steel silencer |
| Ignition: | Digital - inductive type |
| Starting: | Electric |
| Max Power: | 78 kW / 106 hp @ 11850 rpm |
| Max Torque: | 68 Nm / 6.9 kgf-m / 50 ft/lb @ 9750 rpm |
| Clutch: | Wet multiplate |
| Transmission: | 6 Speed |
| Final Drive: | O ring, chain |
| Frame: | Aluminium beam twin spar. Rear - 2 piece high pressure die cast swingarm, twin-sided, cast aluminium alloy |
| Front Suspension: | 41mm Kayaba telescopic upside down forks |
| Front Wheel Travel: | 110 mm / 4.3 in |
| Rear Suspension: | Kayaba monoshock, adjustable preload |
| Rear Wheel Travel: | 124.5 mm / 4.9 in |
| Front Brakes: | 2 x 310 mm Floating discs, Nissen 2 piston sliding calipers,ABS |
| Rear Brakes: | Single 220 mm disc, Brembo 1 piston caliper, ABS |
| Wheel Front: | Cast aluminium alloy 5-spoke, 17 x 3.5in |
| Wheel Rear: | Cast aluminium alloy 5-spoke, 17 x 5.5in |
| Front Tyre: | 120/70 ZR 17 |
| Rear Tyre: | 180/55 ZR 17 |
| Dimensions: | Length: 2055mm / 80.8in Width: 740mm / 29.1in (handle bard) Height: 1060mm / 41.7in (without mirrors) |
| Wheelbase: | 1410 mm / 55.5in |
| Rake: | 24.1º |
| Trail: | 99.6 mm / 3.92 in |
| Seat Height: | 800 mm / 31.5 in |
| Dry Weight: | 168 kg / 370 lbs |
| Wet Weight: | 188 kg / 414 lbs |
| Fuel Capacity: | 17.4 Litres / 4.6 US gal / 3.8 Imp gal |
| Consumption Average: | 5.1 L/100 km / 19.8 km/l / 46.6 US mpg / 55.9 Imp mpg |
| Standing ¼ Mile: | 11.6 sec |
| Top Speed: | 223.1 km/h / 138.6 mph |
