Triumph Sprint RS (2002) technical specifications
Triumph Sprint RS is produced in 2002. Engine is Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder, displacement 955 cc / 58.3 cu in , produces power 87.5 kW / 120 hp @ 9100 rpm and 100 Nm / 10.2 kg-m 73.8 lb-ft @ 5100 rpm. Triumph Sprint RS top speed is 238.3 km/h. Triumph Sprint RS weighs 199 kg / 438 lbs. Triumph Sprint RS has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Sprint RS |
| Years: | 2002 |
| Engine: | Four stroke, transverse three cylinder. DOHC, 4 valves per cylinder |
| Capacity: | 955 cc / 58.3 cu in |
| Cooling System: | Liquid cooled |
| Bore x Stroke: | 79 x 65 mm |
| Lubrication: | Wet sump |
| Compression Ratio: | 12.0:1 |
| Induction: | Multipoint sequential electronic fuel injection |
| Engine Oil: | Synthetic, 10W/40 |
| Ignition: | Digital CDI |
| Spark Plug: | NGK, CR9EK |
| Starting: | Electric |
| Max Power: | 87.5 kW / 120 hp @ 9100 rpm |
| Max Torque: | 100 Nm / 10.2 kg-m 73.8 lb-ft @ 5100 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Frame: | Aluminium, twin spar |
| Front Suspension: | 45 mm Forks with dual rate springs and adjustable preload |
| Rear Suspension: | Monoshock with adjustable preload, compression and rebound damping |
| Front Brakes: | 2 x 320 mm Discs, 4 piston calipers |
| Rear Brakes: | Single 255 mm disc, 2 piston caliper |
| Wheels Front: | Alloy 3 spoke, 17 x 3.5in |
| Wheels Rear: | Alloy 3 spoke, 17 x 5.5in |
| Front Tyre: | 120/70-17 |
| Rear Tyre: | 180/55-17 |
| Rake: | 24.5º |
| Trail: | 80 mm / 3.1 in |
| Dimensions: | Length 2120 mm / 83.5 in Width 735 mm / 28.9 in (handlebars) Height 1170 mm / 46.1 in |
| Wheelbase: | 1470 mm / 57.9 in |
| Seat Height: | 805 mm / 31.7 in |
| Dry Weight: | 199 kg / 438 lbs |
| Fuel Capacity: | 19.5 Litres / 5.2 US gal / 4.3 Imp gal |
| Consumption Average: | 19.8 km |
| Standing ¼ Mile: | 11.2 sec |
| Top Speed: | 238.3 km/h |
