Triumph Scrambler 1200 XE (2024) technical specifications

Triumph Scrambler 1200 XE is produced in 2024. Engine is Four stroke, 270? crank angle parallel twin, SOHC, 4 valves per cylinder, displacement 1197 cc / 73.0 cu-in , produces power 89 hp / 66.2 kW @ 7250 rpm and 110 Nm / 81.1 lb-ft @ 4500 rpm. Triumph Scrambler 1200 XE wet weight is 230 kg / 507 lbs. Triumph Scrambler 1200 XE has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Scrambler 1200 XE
Years:	2024
Engine:	Four stroke, 270? crank angle parallel twin, SOHC, 4 valves per cylinder
Capacity:	1197 cc / 73.0 cu-in
Bore x Stroke:	97.6 x 80.0 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.0:1
Exhaust:	Brushed 2 into 1 exhaust system with single muffler
Emission:	EURO5
Lubrication:	Wet sump
Induction:	Multipoint sequential electronic fuel injection
Ignition:	Digital ? inductive type
Starting:	Electric
Max Power:	89 hp / 66.2 kW @ 7250 rpm
Max Torque:	110 Nm / 81.1 lb-ft @ 4500 rpm
Clutch:	Wet, multi-plate torque assist
Transmission:	6 Speed
Final Drive:	X ring chain
Frame:	Tubular steel with aluminum swingarm
Front Suspension:	47mm Marzocchi fully adjustable USD forks
Front Wheel Travel:	249 mm / 9.8 in
Rear Suspension:	Marzocchi fully adjustable piggy-back RSUs with twin springs
Rear Wheel Travel:	249 mm / 9.8 in
Front Brakes:	2x 310mm discs with 2-piston Nissen calipers
Rear Brakes:	Single 255mm disc with single-piston Nissen caliper
ABS:	Cornering aware ABS
Wheel Front:	36-spoke 21 x 2.15 in, aluminum rims
Wheel Rear:	32-spoke 17 x 4.25 in, aluminum rims
Front Tyre:	90/90-21
Rear Tyre:	150/70 R17
Rake:	26.9?
Trail:	125 mm / 4.9 in
Dimensions:	Length 2330 mm / 91.7 in Width 905 mm / 35.6 in with handlebars Height 1250 mm / 49.2 in without mirrors
Wheelbase:	1570 mm / 61.8 in
Seat Height:	870 mm / 34.3 in
Wet Weight:	230 kg / 507 lbs
Fuel Capacity:	15 Litres / 4.0 US gal
Instruments:	Full-colour TFT instruments
