Triumph Scrambler 1200 XC Gold Line Edition (2022) technical specifications

Triumph Scrambler 1200 XC Gold Line Edition technical specifications

Triumph Scrambler 1200 XC Gold Line Edition is produced in 2022. Engine is Four stroke, 270° crank angle parallel twin, SOHC, 4 valves per cylinder, displacement 1200 cc / 73.2 cu-in , produces power 89 hp / 66.2 kW @ 7250 rpm and 110 Nm / 81.1 lb-ft @ 4500 rpm. Triumph Scrambler 1200 XC Gold Line Edition wet weight is 230 kg / 507 lbs. Triumph Scrambler 1200 XC Gold Line Edition has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Scrambler 1200 XC Gold Line Edition
Years: 2022
Engine: Four stroke, 270° crank angle parallel twin, SOHC, 4 valves per cylinder
Capacity: 1200 cc / 73.2 cu-in
Bore x Stroke: 97.6 x 80.0 mm
Cooling System: Liquid cooled
Compression Ratio: 11.0:1
Exhaust: Brushed 2 into 2 exhaust system with brushed high level silencers
Emission: EURO5
Lubrication: Wet sump
Induction: Multipoint sequential electronic fuel injection
Ignition: Digital – inductive type
Starting: Electric
Max Power: 89 hp / 66.2 kW @ 7250 rpm
Max Torque: 110 Nm / 81.1 lb-ft @ 4500 rpm
Clutch: Wet, multi-plate assist
Transmission: 6 Speed
Final Drive: X ring chain
Frame: Tubular steel with aluminum cradles, Twin-sided, aluminum, 547 mm long swingarm
Front Suspension: 45mm Showa fully adjustable USD forks
Front Wheel Travel: 200 mm / 7.9 in
Rear Suspension: Öhlins fully adjustable piggy-back RSUs with twin springs
Rear Wheel Travel: 200 mm / 7.9 in
Front Brakes: 2x 320mm discs, Brembo M50 monoblock calipers, radial master cylinder
Rear Brakes: Single 255mm disc, Brembo 2-piston floating caliper
ABS: Switchable ABS
Wheel Front: 36-spoke 21 x 2.15, aluminum rims
Wheel Rear: 32-spoke 17 x 4.25, aluminum rims
Front Tyre: 90/90-21
Rear Tyre: 150/70 R17
Rake: 25.8°
Trail: 121 mm / 4.8 in
Dimensions: Length 2286 mm / 90.0 in Width 840.7 mm / 33.1 in handlebars Height 1200 mm / 47.2 in without mirrors
Wheelbase: 1530 mm / 60.2 in
Seat Height: 840 mm / 33.1 in
Wet Weight: 230 kg / 507 lbs
Fuel Capacity: 16 Litres / 4.2 US gal
Instruments: Full-colour TFT instruments
