Suzuki GSX-S 750 (2017-18) technical specifications

Suzuki GSX-S 750 technical specifications

Suzuki GSX-S 750 is produced in 2017-18. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC, displacement 749 cc / 45.7 cub. in , produces power 73.8 kW / 99.1 hp @ 10170 rpm and 73.6 Nm / 54.3 lb-ft / @ 9060 rpm. Suzuki GSX-S 750 wet weight is 213 kg / 469.6 lbs. Suzuki GSX-S 750 has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: GSX-S 750
Years: 2017-18
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC
Capacity: 749 cc / 45.7 cub. in
Bore x Stroke: 72.0 x 46.0 mm
Compression Ratio: 12.3:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Induction: Suzuki Fuel Injection with SDTV
Ignition: Electronic ignition (transistorised)
Traction Control: Suzuki Advanced Traction Control
Starting: Electric
Max Power: 73.8 kW / 99.1 hp @ 10170 rpm
Max Torque: 73.6 Nm / 54.3 lb-ft / @ 9060 rpm
Clutch: Wet, multi-plate type
Transmission: 6 Speed, constant mesh
Final Drive: Chain, DID50VAZ, 114 links
Frame: Aluminium, twin spar
Front Suspension: Inverted telescopic, coil spring, oil damped
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Link type, coil spring, oil damped, 7-way adjustable
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2x 310 mm Full floating discs, 4-piston calipers
Rear Brakes: Single 220 mm disc, Nissin, 1-piston caliper
Front Tyre: 120/70ZR17M/C (58W), tubeless
Rear Tyre: 180/55ZR17M/C (73W), tubeless
Dimensions: Length 2125 mm / 83.6 in Width 785 mm / 30.9 in Height 1055 mm / 41.5 in
Wheelbase: 1455 mm / 57.2 in
Seat Height: 820 mm / 32.2 in
Ground Clearance: 135 mm / 5.1 in
Wet Weight: 213 kg / 469.6 lbs
Fuel Capacity: 16 Litres / 4.2 US gal / 3.7 Imp gal
