Piaggio MP3 Hybrid LT 300ie (2010) technical specifications

Piaggio MP3 Hybrid LT 300ie technical specifications

Piaggio MP3 Hybrid LT 300ie is produced in 2010. Engine is Four stroke, single cylinder, SOHC, 4 valve, displacement 278 cc / 17.0 cub in. , produces power 18.6 kW / 25 hp @ 7500 rpm + 3 kW / 4 hp electric motor. Piaggio MP3 Hybrid LT 300ie weighs 257 kg / 566.6 lbs. Piaggio MP3 Hybrid LT 300ie has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: MP3 Hybrid LT 300ie
Years: 2010
Engine: Four stroke, single cylinder, SOHC, 4 valve
Capacity: 278 cc / 17.0 cub in.
Bore x Stroke: 75 mm x 63 mm
Cooling System: Liquid cooled
Induction: Fuel system: Electronic fuel injection (with Ride By Wire control)
Ignition: Port Injected Alfa/n type with closed loop system, Lambda sensor in exhaust pipe and three-way double catalytic converter
Starting: Electric
Max Power: 18.6 kW / 25 hp @ 7500 rpm + 3 kW / 4 hp electric motor
Max Toque: 23.2 Nm @ 6500 rpm
Clutch: Automatic, centrifugal dry clutch
Transmission: CVT with torque server
Final Drive: Belt
Frame: Double cradle in high strength tubular steel
Front Suspension: Articulated quadrilateral consisting of four aluminium arms sustaining two steering tubes, and pull rod suspension geometry with offset wheel axle
Front Wheel Travel: 85 mm / 3.3 in.
Rear Suspension: Double dual action hydraulic shock absorber with adjustable spring preload
Rear Wheel Travel: 110 mm / 4.3 in
Front Brakes: 2x 240mm discs, One disc brake per wheel, c 2 piston caliper
Rear Brakes: Single 240mm disc
Front Tyre: 2 x 120/70 -12
Rear Tyre: 140/70 -12
Dimensions: Length: 2180 mm / 85.8 in. Width: 760 mm / 29.9 in.
Wheelbase: 1550 mm / 61.0 in.
Seat Height: 780 mm / 30.7 in.
Dry Weight: 257 kg / 566.6 lbs
Fuel Capacity: 12 Litres / 3.2 gal
Reserve: 1.8 L / 0.5 US gal
Consumption Average: 1.7 L/100 km / 60 km/l / 141 US mpg
Colours: Pearl white with two-tone saddle or black saddle, Red
