NSU Sportmax (1954-56) technical specifications

NSU Sportmax is produced in 1954-56. Engine is Single cylinder, 4 stroke, OHC, displacement 247 cc / 15 cub in , produces power 20.6 kW / 28 hp @ 10 00 rpm. NSU Sportmax top speed is 212 km/h / 131.7+ mph. NSU Sportmax wet weight is 155 kg / 342 lbs. NSU Sportmax has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Sportmax
Years:	1954-56
Engine:	Single cylinder, 4 stroke, OHC
Capacity:	247 cc / 15 cub in
Bore x Stroke:	69 x 66 mm
Cooling:	Air/Oil cooled
Lubrication:	Dry sump
Clutch:	Multi-plate
Starting:	Kick start
Ignition:	Coil
Carburetor:	BING 2/26/25
Exhaust System:	Twin, steel
Max Power:	20.6 kW / 28 hp @ 10 00 rpm
Compression Ratio:	7.4:1
Transmission:	Four speed block
Final Drive:	Chain
Frame:	Single-bar stamped plate with engine protection and suspended
Front suspension:	Swining link suspension
Rear suspension:	Telescopic suspension
Brakes (front and back):	Drum
Wet Weight:	155 kg / 342 lbs
Top Speed:	212 km/h / 131.7+ mph
