NSU 501 SS (1931-34) technical specifications
NSU 501 SS is produced in 1931-34. Engine is Single cylinder, up-right shaft 4 stroke, OHC, displacement 494 cc / 30.1 cub in , produces power 14.7 kW / 20 hp @ 4800 rpm. NSU 501 SS top speed is 100 km/h / 62 mph. NSU 501 SS weighs 165 kg / 364 lbs. NSU 501 SS has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | 501 SS |
| Years: | 1931-34 |
| Engine: | Single cylinder, up-right shaft 4 stroke, OHC |
| Capacity: | 494 cc / 30.1 cub in |
| Bore x Stroke: | 80 x 99 |
| Cooling: | Air/Oil cooled |
| Lubrication: | Gear driven oil pump |
| Ignition: | Magneto |
| Starting: | Kick start |
| Exhaust System: | Dual exhaust (single-port system on racing models) |
| Max Power: | 14.7 kW / 20 hp @ 4800 rpm |
| Compression: | 1:6 |
| Transmission: | 3 Speed, pedal gearshipf |
| Final Drive: | Chain in oil bath |
| Font Suspension: | Spring loaded fork |
| Frame: | Closed frame |
| Wheels: | 19 in, spokes, high pressure tyres |
| Rear Brake: | Internal shoe |
| Dry Weight: | 165 kg / 364 lbs |
| Top Speed: | 100 km/h / 62 mph |
