Norton V4 RR & SS (2017) technical specifications

Norton V4 RR & SS technical specifications

Norton V4 RR & SS is produced in 2017. Engine is Four stroke, 72 ° V-four cylinder, Chain-driven cams with idler gear for reduced engine height. Titanium inlet valves. Slipper clutch, displacement 1200 cc / 73.2 cu in , produces power 200 hp / 149 kW @ 12,500 rpm and 130Nm / 95.8 ft-lb @ 10,000rpm. Norton V4 RR & SS weighs 179kg / 395 lbs. Norton V4 RR & SS has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: V4 RR & SS
Years: 2017
Engine: Four stroke, 72 ° V-four cylinder, Chain-driven cams with idler gear for reduced engine height. Titanium inlet valves. Slipper clutch
Capacity: 1200 cc / 73.2 cu in
Bore x Stroke: 82mm x 56.8mm
Compression Ratio: 13.6:1
Euro 4: Full compliance including oil thermostat, knock sensors, secondary air injection and EVAP
Cooling System: Liquid-cooled
Induction: Electronic fuel-injection system. Constantly variable inlet tracts. 8-fuel injectors. Full drive-by-wire system independent of front and rear banks of cylinders for ultimate control and feel
Electronic Aids: Multi-setting traction-control, wheelie contril, launch control and cruise control. Uses six-axis Inertial Measurement Unit (IMU). Full data-logging capability including: lap times, max lean angle, max speed, max throttle and max braking force. Engine modes - Road, Sport, Pro-Race.
Ignition: Keyless ignition system
Starting: Electric
Instruments: Full-colour 7-inch HD display with multiple functions. Engine mode adjustability including: Road, Track, and Pro-Race
Max Power: 200 hp / 149 kW @ 12,500 rpm
Max Torque: 130Nm / 95.8 ft-lb @ 10,000rpm
Transmission: Full quickshift system and auto down blipper
Final Drive: Chain
Chassis: Cast twin tube shotgun chassis, cast outriggers and headstock, polished tubes. (tbc). Engine acts as a structural member. Chassis is fully-adjustable including swingarm pivot and adjustable rake angle. 23.9 degree steering head angle as standard set-up. Braced and underslung single-sided cast swingarm. 570mm long, design developed in conjunction with SG5 TT race bike.
Front Suspension: Ohlins NIX30 system front fork. Fully-adjustable. Fork yokes - Cast top and bottom
Rear Suspension: Ohlins TTXGP Norton bespoke fully-adjustable rear shock. Fork yokes - Billet machined
Front Brakes: 2 x 330mm full-floating discs. Radially-mounted Brembo monobloc calipers. Brembo discs and Brembo master cylinder
Rear Brakes: Single 330mm disc. Brembo caliper and master cylinder
Front Wheel: Forged Aluminium
Rear Wheel: Forged Aluminium
Wheelbase: 1430mm / 56 in
Dry Weight: 179kg / 395 lbs
Fuel Capacity: 18 litres / 4.7 US gal
