MV Agusta F4-RR 312 1078 / F4 1078RR Edizione Final (2010) technical specifications

MV Agusta F4-RR 312 1078 / F4 1078RR Edizione Final is produced in 2010. Engine is Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder, displacement 1078 cc / 65.7 cu-in , produces power 190 hp / 140 kW @ 10000 rpm and 124 Nm / 91.4 lb-ft @ 8200 rpm. MV Agusta F4-RR 312 1078 / F4 1078RR Edizione Final top speed is 293.8 km/h / 182.5 mph. MV Agusta F4-RR 312 1078 / F4 1078RR Edizione Final weighs 192 Kg / 423.3 lbs. MV Agusta F4-RR 312 1078 / F4 1078RR Edizione Final has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	F4-RR 312 1078 / F4 1078RR Edizione Final
Years:	2010
Engine:	Four stroke, transverse four cylinder. DOHC, 4 valves per cylinder
Capacity:	1078 cc / 65.7 cu-in
Bore x stroke:	79 x 55 mm
Cooling System:	Liquid cooled
Compression ratio:	13.0:1
Engine management system:	"Weber Marelli" 5SM ignition - injection integrated system; induction discharge electronic ignition, "Multipoint" sequential timed electronic injection
Ignition:	Multipoint” electronic injection
Starting:	Electric
Max Power:	190 hp / 140 kW @ 10000 rpm
Max Torque:	124 Nm / 91.4 lb-ft @ 8200 rpm
Clutch:	Wet, multi - disc with mechanical anti-surging device
Transmission:	6 Speed
Final Drive:	Chain
Gear Ratio:	1st 14/37 140.9 Km/h (87.5 mph) at 13000 r.p.m. 2nd 16/33 180.6 Km/h (112.1 mph) at 13000 r.p.m. 3rd 18/31 216.3 Km/h (134.3 mph) at 13000 r.p.m. 4th 20/30 248.3 Km/h (154.2 mph) at 13000 r.p.m. 5th 22/29 282.6 Km/h (175.5 mph) at 13000 r.p.m. 6th 21/25 Over 300 Km/h (186.0 mph) at 13000 r.p.m.
Frame:	CrMo steel tubular trellis
Front Suspension:	Upside-down telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment
Front Wheel Travel:	130 mm / 5.1 in
Rear Suspension:	Progressive, single shock absorber with rebound and compression (High speed / Low speed) damping and spring preload (hydraulic control)
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 320mm discs 4 piston caliper
Rear Brakes:	Single 210mm disc 4 piston caliper
Front Tyre:	120/70 ZR17
Rear Tyre:	180/55 ZR17
Seat Height:	810 mm / 31.8 in
Trail:	103.8 mm / 4.08 in
Dimensions:	Length 2007 mm / 79.01 in Width 685 mm / 26.97 in
Wheelbase:	Wheelbase 1408 mm / 55.40 in
Dry-Weight:	192 Kg / 423.3 lbs
Fuel Capacity:	21 Litres / 5.5 US Gal
Standing ¼ Mile:	11.1 sec
Top Speed:	293.8 km/h / 182.5 mph
