Moto Guzzi V-7 700 (1967-68) technical specifications
Moto Guzzi V-7 700 is produced in 1967-68. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valve per cylinder, displacement 703 cc / 43.9 cu-in , produces power 50 hp / 37.2 kW @ 6300 rpm and 49 Nm / 36 lb-ft @ 5000 rpm. Moto Guzzi V-7 700 weighs 228 kg / 502.6 lbs. Moto Guzzi V-7 700 has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | V-7 700 |
| Years: | 1967-68 |
| Engine: | Four stroke, 90° V twin, longitudinally mounted, OHV, 2 valve per cylinder |
| Capacity: | 703 cc / 43.9 cu-in |
| Bore x Stroke: | 80 x 70 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.0:1 |
| Induction: | Dell'orto SS I 29 DS carburetor |
| Ignition: | Battery & coil |
| Starting: | Electric |
| Max Power: | 50 hp / 37.2 kW @ 6300 rpm |
| Max Torque: | 49 Nm / 36 lb-ft @ 5000 rpm |
| Clutch: | Twin driven dry plates |
| Transmission: | 4 Speed |
| Final Drive: | Shaft |
| Front Suspension: | Telehydraulic forks |
| Rear Suspension: | Swinging arm with hydraulic dampers. |
| Front Brakes: | 2x 220mm drum |
| Rear Brakes: | 220mm drum |
| Front Tyre: | 4.00 -18 |
| Rear Tyre: | 4.00 -18 |
| Dry Weight: | 228 kg / 502.6 lbs |
| Fuel Capacity: | 20 Litres / 5.2 US gal |
