Moto Guzzi V 11 Sport Naked (2002) technical specifications

Moto Guzzi V 11 Sport Naked technical specifications

Moto Guzzi V 11 Sport Naked is produced in 2002. Engine is Four stroke, 90° V twin, longitudinally mounted, OHV, 4 valve per cylinder., displacement 1064 cc / 64.9 cu-in , produces power 91 hp / 66.3 kW @ 7800 rpm and 94 Nm / 69.3 lb-ft @ 6000 rpm. Moto Guzzi V 11 Sport Naked weighs 221 kg / 487.2 lbs. Moto Guzzi V 11 Sport Naked has 2 photos.

Technical specifications

+ Add to 'Compare list'
Model: V 11 Sport Naked
Years: 2002
Engine: Four stroke, 90° V twin, longitudinally mounted, OHV, 4 valve per cylinder.
Capacity: 1064 cc / 64.9 cu-in
Bore x Stroke: 92 x 80 mm
Cooling System: Air cooled
Compression Ratio: 9.8:1
Induction: Magneti Marelli IAW Multipoint phased sequential fuel injection
Ignition: Magneti Marelli IAW electronic digital
Starting: Electric
Max Power: 91 hp / 66.3 kW @ 7800 rpm
Max Torque: 94 Nm / 69.3 lb-ft @ 6000 rpm
Transmission: 5 Speed
Final Drive: Shaft
Front Suspension: 40mm Marzocchi upside-down forks, adjustable compression, 120mm wheel travel.
Rear Suspension: Cantilever swingarm, Sachs Boge mono shock, adjustable compression and rebound damping, 128mm wheel travel.
Front Brakes: 2x 320mm discs 4 piston calipers
Rear Brakes: Single 282mm disc 2 piston caliper
Front Tyre: 120/70-17
Rear Tyre: 180/55-17
Dimensions: Length 2150 mm / 84.6 in Width 785 mm / 30.9 in Height: 1090 mm / 42.9 in
Seat Height: 800 mm / 31.5 in
Wheelbase: 1471 mm / 57.9 in
Dry Weight: 221 kg / 487.2 lbs
Fuel Capacity: 22 Litres / 5.8 US gal
