KTM 250 EXC-E (2008-10) technical specifications

KTM 250 EXC-E technical specifications

KTM 250 EXC-E is produced in 2008-10. Engine is Two stroke, single cylinder, displacement 249 cc / 15.2 cu in KTM 250 EXC-E weighs 107 kg / 235 lbs. KTM 250 EXC-E has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: 250 EXC-E
Years: 2008-10
Engine: Two stroke, single cylinder
Capacity: 249 cc / 15.2 cu in
Bore x Stroke: 66.4 x 72.0 mm
Compression Ratio: 11.0:1
Cooling System: Liquid cooled
Lubrication: Pessure circulation lubrication with 2 rotor pumps
Induction: Keihin MX FCR 39 carburetor
Ignition: Contactless DC-CDI ignition with digital advanced system by KOKUSAN
Starting: Kick and electric
Clutch: Wet, multiplate, hydraulically operated
Transmission: 5 Speed
Final Drive: Chain, 5/8 x 1/4 in
Frame: Central chrome-moly-steel frame
Front Suspension: WP Suspension – 4860 MXMA / MXMA + PA
Front Wheel Travel: 300 mm / 11.8 in
Rear Suspension: WP Suspension – 5018 PDS MCC / DCC, aluminium swing arm
Rear Wheel Travel: 335 mm / 13.2 in
Front Brakes: Single 260 mm disc, floating caliper
Rear Brakes: Single 220 mm disc, floating caliper
Front Tyre: 90/90 - 21
Rear Tyre: 120/80 - 18
Steering Head Angle: 63.5°
Rake: 26.5°
Trail: 112 mm / 4.1 in
Wheelbase: 1475 mm / 58.1 in
Seat Height: 925 mm / 36.4 in
Ground Clearance: 380 mm / 15.1 in
Dry Weight: 107 kg / 235 lbs
Fuel Capacity: 9.5 Litres / 2.5 US gal
