Kawasaki Z-X10RR Ninja Limited Edition (2024) technical specifications

Kawasaki Z-X10RR Ninja Limited Edition technical specifications

Kawasaki Z-X10RR Ninja Limited Edition is produced in 2024. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 998 cc / 60.9 cu-in , produces power 150 kW / 204 hp @ 14000 rpm and 111.8 Nm / 82.4 lb-ft @ 11700 rpm. Kawasaki Z-X10RR Ninja Limited Edition wet weight is 207 kg / 456.4 lbs. Kawasaki Z-X10RR Ninja Limited Edition has 5 photos.

Technical specifications

+ Add to 'Compare list'
Model: Z-X10RR Ninja Limited Edition
Years: 2024
Production: 40 Units
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Capacity: 998 cc / 60.9 cu-in
Bore x Stroke: 76.0 x 55.0 mm
Compression Ratio: 13.0:1
Cooling System: Liquid cooled
Lubrication: Forced lubrication, wet sump with oil cooler
Induction: DFI with 47mm Mikuni throttle bodies (4) and Variable Air Intake System (VAI)
Ignition: TCBI with digital advance and Sport-Kawasaki Traction Control (S-KTRC)
Starting: Electric
Max Power: 150 kW / 204 hp @ 14000 rpm
Max Power Ram Air: 157.5 kW / 214 hp @ 14000 rpm
Max Torque: 111.8 Nm / 82.4 lb-ft @ 11700 rpm
Clutch: Wet multi-disc, manual
Transmission: 6-speed, return, cassette
Final Drive: Sealed Chain
Primary Reduction Ratio: 1.681 (79/47)
Gear Ratio: 1st 2.600 (39/15) 2nd 2.158 (41/19) 3rd 1.882 (32/17) 4th 1.650 (33/20) 5th 1.476 (31/21) 6th 1.304 (30/23)
Final Reduction Ratio: 2.294 (39/17)
Frame: Aluminum perimeter
Front Suspension: 43mm inverted Balance Free Fork, adjustable stepless rebound and compression damping, spring preload adjustability, and top-out springs
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Horizontal back-link with Balance Free gascharged shock, stepless, dual-range (low-/highspeed) compression damping, stepless rebound damping, fully adjustable spring preload
Rear Wheel Travel: 115 mm / 4.5 in
Front Brakes: 2x 330 mm Intelligent Braking (KIBS), Brembo? dual semifloating discs with dual radial mounted monobloc 4-piston calipers
Rear Brakes: Single 220mm disc KIBS-supported with aluminum single-piston caliper
Front Tyre: 120/70 ZR17
Rear Tyre: 190/55 ZR17
Rake: 25?
Trail: 105 mm / 4.2 in
Dimensions: Length 2085 mm / 82.1 in Width 750 mm / 29.5 in Height 1185 mm / 46.7 in
Wheelbase: 1450 mm / 57.1 in
Ground Clearance: 135 mm / 5.3 in
Seat Height: 835 mm / 32.9 in
Wet Weight: 207 kg / 456.4 lbs
Fuel Capacity: 17 Litres / 4.5 US gal
Electronic Rider Aids: ?hlins? Electronic Steering Damper, Kawasaki Launch Control Mode (KLCM), Kawasaki Intelligent anti-lock Brake System (KIBS), Kawasaki Sport Traction Control (S-KTRC), Kawasaki Engine Braking Control, Kawasaki Quick Shifter (KQS) (upshift & downshift), Kawasaki Corner Management Function (KCMF), Power Modes (Full/Mid/Low)
