Kawasaki KLR 650 (2015) technical specifications

Kawasaki KLR 650 technical specifications

Kawasaki KLR 650 is produced in 2015. Engine is Four stroke, single cylinder, DOHC, 4 valves per cylinder, displacement 651 cc / 39.7 cu-in , produces power 42.1 hp / 31 kW @ 7000 rpm and 47 Nm / 4.7 kgf-m @ 5000 rpm. Kawasaki KLR 650 wet weight is 194 kg / 432 lbs. Kawasaki KLR 650 has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: KLR 650
Years: 2015
Engine: Four stroke, single cylinder, DOHC, 4 valves per cylinder
Capacity: 651 cc / 39.7 cu-in
Bore x Stroke: 100 x 83 mm.
Cooling System: Liquid cooled
Compression Ratio: 9.8:1
Induction: Keihin CVK40
Lubrication: Forced lubrication (wet sump)
Engine Oil: Semi-Synthetic, 10W/40
Spark Plug: NGK, DPR 8EA/9
Ignition: Transistorized
Starting: Electric
Max Power: 42.1 hp / 31 kW @ 7000 rpm
Max Torque: 47 Nm / 4.7 kgf-m @ 5000 rpm
Clutch: Wet multi-disc, cable operation
Transmission: 5 Speed
Final Drive: Sealed Chain
Primary Reduction Ratio: 2.272 / 75/33
Gear Ratio: 1st 2.266 (34/15) 2nd 1.444 (26/18) 3rd 1.136 (25/22) 4th 0.954 (21/22) 5th 0.791 (19/24)
Final Reduction Ratio: 2.867 (43/15)
Frame: Semi-double Cradle Made of high-tech, round-section, high-tensile steel
Front Suspension: 41mm Air-adjustable forks,
Front Wheel Travel: 200 mm / 7.8 in
Rear Suspension: UNI-TRAK® linkage, 5-way preload shock absorber with 4way rebound damping.
Rear Wheel Travel: 185 mm / 7.2 in
Front Brakes: Single 280mm disc 2 piston caliper
Rear Brakes: Single 203mm disc 1 piston caliper
Front Tyre: 90/90 -21
Rear Tyre: 130/80 -17
Rake: 28.0°
Trail: 112 mm / 4.4 in
Dimensions: Length 2295 mm / 90.4 in Width 960 mm / 37.8 in Height 1350 mm / 53.1 in
Wheelbase: 1480 mm / 58.3 in
Ground Clearance: 210 mm / 8.3 in
Seat Height: 889 mm / 35 in
Wet Weight: 194 kg / 432 lbs
Fuel Capacity: 23 Litres / 5.8 gal.
