Honda XR 250 (1981) technical specifications
Honda XR 250 is produced in 1981. Engine is Four stroke, single cylinder SOHC, 4 valve, displacement 249 cc / 15.2 cu-in , produces power 30 hp / 21.9 kW @ 9000 rpm and 24.5 Nm / 18 ft-lb @ 7500 rpm. Honda XR 250 weighs 108 kg / 238 lbs. Honda XR 250 has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | XR 250 |
| Years: | 1981 |
| Engine: | Four stroke, single cylinder SOHC, 4 valve |
| Capacity: | 249 cc / 15.2 cu-in |
| Bore x Stroke: | 74 x 57.8 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 10.0:1 |
| Induction: | 2x 30.5 mm piston valve Keihin |
| Ignition: | Capasitor-Discharge |
| Spark Plug: | D&EA, Plug gap .028 |
| Starting: | Kick |
| Max Power: | 30 hp / 21.9 kW @ 9000 rpm |
| Max Torque: | 24.5 Nm / 18 ft-lb @ 7500 rpm |
| Clutch: | Wet, four friction discs |
| Transmission: | 6 Speed |
| Final Drive: | Chain, #520 x 106 |
| Sprockets: | Front 13 T Rear 53 T |
| Front Suspension: | Leading axel air spring 38mm forks |
| Front Wheel Travel: | 245 mm / 9.6 in |
| Rear Suspension: | Pro-link Kayaba damper adjustment for spring preload and rebound damping |
| Rear Wheel Travel: | 247 mm / 9.7 in |
| Front Brakes: | Drum |
| Rear Brakes: | Drum |
| Front Tyre: | 3.00-21 |
| Rear Tyre: | 5.10-17 |
| Seat Height: | 945 mm / 37.2 in |
| Ground Clearance: | 320 mm / 12.6 in |
| Dry Weight: | 108 kg / 238 lbs |
| Fuel Capacity: | 9.8 Litres / 2.6 US gal |
