Honda NV 400 Custom (1983-) technical specifications
Honda NV 400 Custom is produced in 1983-. Engine is Four stroke V-twin cylinders, OHC, 3 valve per cylinder, displacement 349 cc / 21.2 cu-in , produces power 43 hp / 32 kW @ 9500 rpm and 3.5 kgf-m / 25.3 lb-ft @ 7500 rpm. Honda NV 400 Custom weighs 181 kg / 398 lbs. Honda NV 400 Custom has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | NV 400 Custom |
| Years: | 1983- |
| Engine: | Four stroke V-twin cylinders, OHC, 3 valve per cylinder |
| Capacity: | 349 cc / 21.2 cu-in |
| Bore x Stroke: | 71.0 × 50.4 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 10.5:1 |
| Induction: | VD6R carburetor |
| Ignition: | CDI |
| Starting: | Electric |
| Max Power: | 43 hp / 32 kW @ 9500 rpm |
| Max Torque: | 3.5 kgf-m / 25.3 lb-ft @ 7500 rpm |
| Clutch: | Wet multi-plate coil spring |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Gear Ratio: | 1st 2.857 2nd 1.947 1.947 3rd 1.545 1.545 4th 1.280 1.280 5th 1.074 1.074 6th 0.866 0.866 |
| Front Suspension: | Telescopic forks |
| Rear Suspension: | Swinging arm |
| Front Brakes: | Single disc |
| Rear Brakes: | Drum |
| Front Tyre: | 3.50 -18 |
| Rear Tyre: | 130/90-16 |
| Seat Height: | 750 mm / 29.5 in |
| Dry Weight: | 181 kg / 398 lbs |
| Fuel Capacity: | 11 Litres / 2.9 US gal |
