Honda DN-01 (2008-10) technical specifications

Honda DN-01 is produced in 2008-10. Engine is Four stroke, 52°V-Twin, SOHC. 4 valve per cylinder, displacement 680 cc / 41.4 cu-in , produces power 45 kW / 61 hp @ 7500 rpm and 64 Nm / 6.5 kgf-m 6000-. Honda DN-01 top speed is 182.9 km/h / 113.6 mph. Honda DN-01 weighs 268 kg / 501 lbs. Honda DN-01 has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	DN-01
Years:	2008-10
Engine:	Four stroke, 52°V-Twin, SOHC. 4 valve per cylinder
Capacity:	680 cc / 41.4 cu-in
Bore x Stroke:	81 x 66 mm
Cooling System:	Liquid cooled
Compression Ratio:	10.0:1
Lubrication:	Wet sump
Induction:	PGM-F1 Electronic fuel injection40mm throttle bedews
Ignition:	Digital transistorized with electronic advance
Starting:	Electric
Max Power:	45 kW / 61 hp @ 7500 rpm
Max Torque:	64 Nm / 6.5 kgf-m 6000-
Clutch:	HFT Antennal hydraulic control
Transmission:	Continuously variable, hydro-mechanical two-mode automatic with six-speed manual mode
Final Drive:	Shaft
Frame:	Double cradle steel tube
Front Suspension:	41mm Telescopic forks
Front Wheel Travel:	106 mm / 4.0 in
Rear Suspension:	Single conventional dampers with 7-step adjustment spring preload
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	130/70 ZR17
Rear Brakes:	190/50 ZR17
Front Tyre:	2x 296 discs 3 piston caliper
Rear Tyre:	Single 276mm disc 2 piston caliper
Rake:	28.5°
Trail:	110 mm / 4.5 in
Dimensions:	Length 1830 mm / 72.0 in Height 1020 mm / 40.0 in
Wheelbase:	1609 mm / 63.3 in
Seat Height:	713 mm / 28.1 in
Dry Weight:	268 kg / 501 lbs
Fuel Capacity:	15 Litres / 3.4 US gal
Consumption Average:	19.2 km/lit
Standing ¼ Mile:	15.1 sec
Top Speed:	182.9 km/h / 113.6 mph
