Honda CBR 500R (2022) technical specifications

Honda CBR 500R is produced in 2022. Engine is Four stroke, parallel-twin, DOHC, 4 valves per cylinder, displacement 471 cc / 28.7 cu-in , produces power 46.9 hp / 35 kW @ 8600 rpm and 43 Nm / 31.7 lb-ft @ 6500 rpm. Honda CBR 500R wet weight is 192 kg / 423 lbs. Honda CBR 500R has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	CBR 500R
Years:	2022
Engine:	Four stroke, parallel-twin, DOHC, 4 valves per cylinder
Capacity:	471 cc / 28.7 cu-in
Bore x Stroke:	67.0 x 66.8 mm
Compression Ratio:	10.7:1
Cooling System:	Liquid cooled
Induction:	PGM-FI with 34mm throttle bodies
Emission:	EURO5
Ignition:	Computer-controlled digital transistorized with electronic advance
Starting:	Electric
Max Power:	46.9 hp / 35 kW @ 8600 rpm
Max Torque:	43 Nm / 31.7 lb-ft @ 6500 rpm
Clutch:	Wet multiplate, Assisted slipper clutch
Transmission:	6 Speed
Final Drive:	O-ring-sealed chain
Frame:	Steel diamond
Front Suspension:	41mm Showa SFF-BP Inverted fork, pre-load adjustable
Front Wheel Travel:	109 mm / 4.3 in
Rear Suspension:	Prolink mono with 5 stage pre-load adjuster, Steel hollow cross swingarm
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 296mm wave disc with Nissin radial-mount two piston calipers
Rear Brakes:	Single 240mm wave disc 1 piston calipers
ABS:	2-channel
Wheels:	5Y-Spoke Cast Aluminium
Front Rim:	17 x MT3.5
Rear Rim:	17 x MT4.5
Front Tyre:	120/70ZR17M/C (58W)
Rear Tyre:	160/60ZR17M/C (69W)
Rake (Caster Angle):	25.5°
Trail:	102 mm / in
Dimensions:	Length: 2080 mm / 81.8 in Width: 760 mm / 29.9 in Height: 1145 mm / 45 in
Wheelbase:	1410 mm / 55.5 in
Seat Height:	785 mm / 30.9 in
Ground Clearance:	130 mm / 5.1 in
Wet Weight:	192 kg / 423 lbs
Fuel Capacity:	17.1 Litres / 4.4 US gal
