Harley-Davidson Harley Davidson XL 53C Sportster Cuustom (1998-03) technical specifications
Harley-Davidson Harley Davidson XL 53C Sportster Cuustom is produced in 1998-03. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder, displacement 883 cc / 53.8 cu-in , produces power 53 hp / 38.6 kW @ 6000 rpm and 67 Nm / 49.4 lb-ft @ 4100 rpm. Harley-Davidson Harley Davidson XL 53C Sportster Cuustom weighs 245.0 kg / 540.1 lbs. Harley-Davidson Harley Davidson XL 53C Sportster Cuustom has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson XL 53C Sportster Cuustom |
| Years: | 1998-03 |
| Engine: | Four stroke, 45° V-Twin, OHV, 2 valves per cylinder |
| Capacity: | 883 cc / 53.8 cu-in |
| Bore x Stroke: | 76.2 x 96.8 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 8.8:1 |
| Lubrication: | Dry sump, gear drive pump with full flow spin-on disposable oil filter |
| Induction: | Carburettor, 40 mm constant velocity with enrichener and accelerator pump |
| Ignition: | Inductive, battery-powered,V Fire III™ electronic breakerless with solid-state dual stage advance |
| Starting: | Electric |
| Max Power: | 53 hp / 38.6 kW @ 6000 rpm |
| Max Torque: | 67 Nm / 49.4 lb-ft @ 4100 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Belt |
| Gear Ratio: | 1st 9.717 2nd 6.690 3rd 5.180 4th 4.267 5th 3.615P |
| Frame: | Mild steel twin cradle |
| Front Suspension: | 35mm Showa telescopic forks. |
| Rear Suspension: | Dual shocks with adjustable damping |
| Front Brakes: | Single 292mm disc 2 piston calipers |
| Rear Brakes: | Single 292mm disc 1 piston calipers |
| Front Tyre: | 80/90-19 |
| Rear Tyre: | 130/90-16 |
| Dimensions: | Length 2245 mm / 88.4 in |
| Wheelbase: | 1510 mm / 59.4 in |
| Seat Height: | 700 mm / 27.6 in |
| Ground Clearance: | 159 mm / 6.3 in |
| Dry Weight: | 245.0 kg / 540.1 lbs |
| Fuel Capacity: | 12.5 Litres / 3.3 US gal |
