Harley-Davidson Harley Davidson Road Glide ST CVO (2024) technical specifications

Harley-Davidson Harley Davidson Road Glide ST CVO is produced in 2024. Engine is Four stroke, V-Twin, Milwaukee-Eight 21, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1977 cc / 120.6 cu-in , produces power 127 hp / 93.4 kW @ 4900 rpm and 197 Nm / 145 lb-ft @ 4000 rpm. Harley-Davidson Harley Davidson Road Glide ST CVO wet weight is 380 kg / 838 lbs. Harley-Davidson Harley Davidson Road Glide ST CVO has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson Road Glide ST CVO
Years:	2024
Engine:	Four stroke, V-Twin, Milwaukee-Eight 21, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Capacity:	1977 cc / 120.6 cu-in
Bore x Stroke:	103.5 x 117.5 mm
Cooling System:	Air and oil cooled
Compression Ratio:	11.4:1
Exhaust:	2-1-2 dual exahust, Titanium mufflers with carbon fibre end caps
Induction:	Electronic sequential port fuel injection (ESPFI)
Lubrication:	Pressurized, dry-sump with oil cooler
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Power:	127 hp / 93.4 kW @ 4900 rpm
Max Torque:	197 Nm / 145 lb-ft @ 4000 rpm
Clutch:	Pressurized, dry-sump with oil cooler
Transmission:	6-Speed, cruise drive
Primary Drive:	Chain, 34/46 ratio
Final Drive:	Belt, 32/68 ratio
Gear Ratio:	1st 10.233 2nd 7.093 3rd 5.268 4th 4.266 5th 3.635 6th 3.067
Frame:	Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded
Swingarm:	Mild steel; two-piece drawn and welded section; forged junctions; MIG welded
Front Suspension:	47mm Inverted 1x1 Front fork with adjustable preload, compression damping and rebound damping
Front Wheel Travel:	117 mm / 4.6 in
Rear Suspension:	Emulsion suspension with adjustable preload, compression and rebound damping
Rear Wheel Travel:	76 mm / 3 in
Front Brakes:	2 x 320mm discs, 32 mm 4-piston fixed dual radially mounted front,
Rear Brakes:	Single 300mm disc, 4 piston fixed caliper
ABS:	Standard
Wheels:	Black, 7-spoke cast aluminium
Front Rim:	19 x 3.5 in
Rear Rim:	18 x 5.0 in
Front Tyre:	130/60B19 61H
Rear Tyre:	180/55B18 80H
Rake:	26?
Trail:	170 mm / 6.7 in
Dimensions:	Length 2410 mm / 94.9 in
Wheelbase:	1625 mm / 64 in
Seat Height:	719 mm / 28.3 in
Ground Clearance:	130 mm / 5.1 in
Wet Weight:	380 kg / 838 lbs
Fuel Capacity:	22.7 Litres / 6.0 US gal
