Harley-Davidson Harley Davidson Pan America 1250 CVO (2024) technical specifications

Harley-Davidson Harley Davidson Pan America 1250 CVO is produced in 2024. Engine is Four stroke, 60? V-twin Revolution Max 1250, Chain-driven, DOHC, hydraulic self-adjusting lifters, intake & exhaust VVT, four valves per cylinder, displacement 1252 cc / 76.3 cu-in , produces power 150 hp / 112 kW @ 8750 rpm and 128 Nm / 94 lb-ft @ 6750 rpm. Harley-Davidson Harley Davidson Pan America 1250 CVO weighs 284 kg / 626 lbs. Harley-Davidson Harley Davidson Pan America 1250 CVO has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson Pan America 1250 CVO
Years:	2024
Engine:	Four stroke, 60? V-twin Revolution Max 1250, Chain-driven, DOHC, hydraulic self-adjusting lifters, intake & exhaust VVT, four valves per cylinder
Capacity:	1252 cc / 76.3 cu-in
Bore x Stroke:	105 x 72.3 mm
Compression Ratio:	13.0:1
Cooling System:	Liquid cooled
Exhaust:	2-into-1-into-1, catalyst in header
Lubrication:	Semi-dry sump
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Starting:	Electric
Max Power:	150 hp / 112 kW @ 8750 rpm
Max Torque:	128 Nm / 94 lb-ft @ 6750 rpm
Clutch:	Mechanical, 8 plate wet, assist & slip, 1090N
Transmission:	6 Speed
Final Drive Ratio:	Chain, 19/48
Primary Drive Ratio:	Gear, 49/89
Gear Ratios:	1st 13.11 / 2nd 9.687 / 3rd 7.509 / 4th 6.057 / 5th 5.08 / 6th 4.436
Frame:	Stressed-member, high strength low alloy steel trellis frame; stamped, cast, and forged junctions; MIG welded; aluminum forged mid-structure
Swingarm:	One-piece cast aluminum
Front Suspension:	47mm inverted fork with electronically adjustable semi-active damping control (optional: Adjustable Right Height (ARH)), Aluminum fork triple clamps
Front Wheel Travel:	191 mm / 7.5 in
Rear Suspension:	Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping, adjustable Ride Height (ARH)
Rear Wheel Travel:	191 mm / 7.5 in
Front Brakes:	2 x 320mm discs, radially mounted, monoblock, 4-piston caliper
Rear Brakes:	Single 280mm disc, floating, single piston caliper
ABS System:	Standard
Wheels:	Aluminum cast, satin black (optional: annodized aluminum tubeless laced)
Front Rim:	3.0 x 19
Rear Rim:	4.50 x 17
Front Tyre:	120/70R19 60V, MIchelin Scorcher Adventure Radial
Rear Tyre:	170/60R17 72V, MIchelin Scorcher Adventure Radial
Rake:	25?
Trail:	108 mm / 4.3 in
Dimensions:	Length: 2345 mm / 92.3 in
Wheelbase:	1585 mm / 62.4 in
Seat Height Unladen:	830 - 855 mm / 32.7 - 33.7 in
Ground Clearance:	180mm / 7.1 in
Dry Weight:	284 kg / 626 lbs
Wet Weight:	299 kg / 659 lbs
Fuel Capacity:	21.2 Litres / 5.6 US gal
