Harley-Davidson Harley Davidson FXDL/I Dyna Low Rider (2002-03) technical specifications
Harley-Davidson Harley Davidson FXDL/I Dyna Low Rider is produced in 2002-03. Engine is Four stroke, 45° V-Twin, OHV,, displacement 1449 cc / 76.3 cu-in , produces power 67 hp / 48.8 kW @ 5200 rpm and 107 Nm / 10.8 kgf-m @ 3300 rpm. Harley-Davidson Harley Davidson FXDL/I Dyna Low Rider has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FXDL/I Dyna Low Rider |
| Years: | 2002-03 |
| Engine: | Four stroke, 45° V-Twin, OHV, |
| Capacity: | 1449 cc / 76.3 cu-in |
| Bore x Stroke: | 95.3 x 101.6 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 8.9:1 |
| Induction: | Carburettor. 40mm CV with enricher and accelerator pump |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Power: | 67 hp / 48.8 kW @ 5200 rpm |
| Max Torque: | 107 Nm / 10.8 kgf-m @ 3300 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Belt 70/32 ratio (68/32 ratio) |
| Gear rRatio: | 1st 10.110 2nd 6.958 3rd 4.953 4th 3.862 5th 3.150 |
| Frame: | Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded |
| Front Suspension: | 39 mm w/ polished aluminum fork triple clamp and dual-rate springs |
| Rear Suspension: | Coil over dual shock |
| Front Brakes: | Single 292mm disc |
| Rear Brakes: | Single 292mm disc |
| Front Tyre: | D401F 100/90-19 57H |
| Rear Tyre: | D401 150/80B16 71H |
| Rake: | 29° |
| Fork Angle 30.5°: | 30° |
| Trail: | 114.3 mm / 4.5 in |
| Dimensions: | Length 2364.0 mm / 93.1 in |
| Seat Height: | Laden2 655 mm / 25.8 in. Unladen 680 mm / 26.80 in. |
| Wheelbase: | 1640 mm / 64.6 in |
| Ground Clearance: | 142.0 mm / 5.6 in |
| Fuel Capacity: | 18.5 Litres / 4.89 US gal |
