Harley-Davidson Harley Davidson FXDF Dyna Fat Bob (2008) technical specifications

Harley-Davidson Harley Davidson FXDF Dyna Fat Bob is produced in 2008. Engine is Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1584 cc / 96 cu-in Harley-Davidson Harley Davidson FXDF Dyna Fat Bob weighs 303.7 kg / 7 lbs. Harley-Davidson Harley Davidson FXDF Dyna Fat Bob has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson FXDF Dyna Fat Bob
Years:	2008
Engine:	Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Capacity:	1584 cc / 96 cu-in
Bore x Stroke:	95.3 x 111.1 mm
Cooling System:	Air cooled
Compression Ratio:	9.2:1
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	124.7 Nm / 92 ft/ lbs. @ 3000 rpm
Clutch:	Multi-plate, wet
Transmission:	6 Speed
Final Drive:	Belt
Gear Ratio:	1st 9.312 / 2nd 6.421 / 3rd 4.774 / 4th 3.926 / 5th 3.279 / 6th 2.79
Frame:	Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension:	49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear Suspension:	Coil over shock
Front Brakes:	2x 299mm disc 4 piston caliper
Rear Brakes:	Single 292mm disc 2 piston caliper
Front Tyre:	D427F 130/90B16 67H
Rear Tyre:	D427 180/70B16 77H
Rake:	29°
Fork Angle:	28°
Trail:	125 mm / 4.9 in
Dimensions:	Length 2329.9 mm / 91.7 in width 889.76 mm / 35.0 in Height 1131.82 mm / 44.5 in
Wheelbase:	1619.7 mm / 63.7 in
Seat Height:	Laden2 663 mm / 26.1 in Unladen 686 mm / 27.0 in
Dry Weight:	303.7 kg / 7 lbs
Wet Weight:	320.0 kg / 706 lbs
Gross Vehicle Weight Rating:	392.2 kg / 1085 lbs
Fuel Capacity:	18 9 Litres / 5.0 US gal
