Harley-Davidson Harley Davidson FXDC Dyna Super Glide Custom (2013) technical specifications

Harley-Davidson Harley Davidson FXDC Dyna Super Glide Custom technical specifications

Harley-Davidson Harley Davidson FXDC Dyna Super Glide Custom is produced in 2013. Engine is Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1584 cc / 96 cu-in Harley-Davidson Harley Davidson FXDC Dyna Super Glide Custom weighs 291 kg / 641 lbs. Harley-Davidson Harley Davidson FXDC Dyna Super Glide Custom has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FXDC Dyna Super Glide Custom
Years: 2013
Engine: Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Capacity: 1584 cc / 96 cu-in
Bore x Stroke: 95.3 x 111.1 mm
Cooling System: Air cooled
Compression Ratio: 9.2:1
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starting: Electric
Max Torque: 124.7 Nm / 92 ft/ lbs. @ 3000 rpm
Transmission: 6 Speed
Final Drive: Belt
Gear Ratio: 1st 9.312 2nd 6.266 3rd 4.774 4th 3.926 5th 3.179 6th 2.790
Frame: Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension: 49 mm with polished aluminum fork triple clamp and dual-rate springs,
Rear Suspension: Coil over shock ,
Front Brakes: Single 300mm disc 4 piston caliper
Rear Brakes: Single 292mm disc 4 piston caliper
Front Tyre: 100/90-19 57H
Rear Tyre: 160/70B17 73V
Rake: 29°
Fork Angle: 30.5°
Trail: 114 mm / 4.3 in
Dimensions: Length 2364.0 mm / 93.1 in Width 921.0 mm / 36.3 in Height 1194.0 mm / 47.0 in
Wheelbase: 1640.0 mm / 64.6 in
Seat Height: Laden2 655.3 mm / 25.8 in Unladen 680.0 mm / 26.8 in
Ground Clearance: 142 mm / 5.6 in
Dry Weight: 291 kg / 641 lbs
Wet Weight: 308.0 kg / 679 lbs
Fuel Capacity: 18 2 Litres / 4.8 US gal
