Harley-Davidson Harley Davidson FLTRX-SE2 Road Glide Custom CVO 110th Anniversary (2013) technical specifications
Harley-Davidson Harley Davidson FLTRX-SE2 Road Glide Custom CVO 110th Anniversary is produced in 2013. Engine is Four stroke, Twin Cam 110™ Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, displacement 1804 cc / 110.1 cub in. Harley-Davidson Harley Davidson FLTRX-SE2 Road Glide Custom CVO 110th Anniversary wet weight is 383.2 kg / 845 lbs. Harley-Davidson Harley Davidson FLTRX-SE2 Road Glide Custom CVO 110th Anniversary has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLTRX-SE2 Road Glide Custom CVO 110th Anniversary |
| Years: | 2013 |
| Engine: | Four stroke, Twin Cam 110™ Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder |
| Capacity: | 1804 cc / 110.1 cub in. |
| Bore x Stroke: | 101.6 x 111.3 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.15:1 |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 165 Nm / 122 lb-ft @ 3750 rpm |
| Clutch: | Hydraulically actuated, 9-plate, wet, with high performance spring |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Gear Ratio: | 1st 9.593 / 2nd 6.650 / 3rd 4.938 / 4th 4.000 / 5th 3.407 / 6th 2.875 |
| Frame: | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded |
| Front Suspension: | 41.3 mm telescopic, triple circuit damping |
| Rear Suspension: | Air-adjustable, Swingarm Mild steel; two-piece drawn and welded section; forged juctions; MIG welded |
| Front Brakes: | 2x 300mm discs 4 piston calipers |
| Rear Brakes: | Single 300mm discs 4 piston caliper |
| Front Tyre: | 130/70B18 |
| Rear Tyre: | 180/55B18 |
| Rake / Trail: | 26° / 170 mm |
| Dimensions: | Length 2443 mm / 96.2 in Width 909 mm / 35.8 in. Height 1340 mm / 52.8 in |
| Seat Height: | Laden2 676 mm / 26.6 in Unladen 699 mm / 27.5 in |
| Gross Axle Weight Rating:: | 616.8 kg / 1360 lbs |
| Wet Weight: | 383.2 kg / 845 lbs |
| Oil Capacit: | 3.8 Litres |
| Fuel Capacity: | 22.7 Litres / 6 gal |
