Harley-Davidson Harley Davidson FLSTSC Softail Springer Classic (2007) technical specifications

Harley-Davidson Harley Davidson FLSTSC Softail Springer Classic technical specifications

Harley-Davidson Harley Davidson FLSTSC Softail Springer Classic is produced in 2007. Engine is Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1584 cc / 96 cu-in Harley-Davidson Harley Davidson FLSTSC Softail Springer Classic weighs 321 kg / 708 lbs. Harley-Davidson Harley Davidson FLSTSC Softail Springer Classic has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FLSTSC Softail Springer Classic
Years: 2007
Engine: Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Capacity: 1584 cc / 96 cu-in
Bore x Stroke: 95.2 x 111.2 mm
Cooling System: Air cooled
Compression Ratio: 9.2:1
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starring: Electric
Max Torque: 124.7 Nm / 92 ft. lbs @ 3000 rpm
Transmission: 6 Speed
Final Drive: Belt
Gear Ratio: 1st 9.312 9.312 9.030 2st 6.421 6.421 6.226 3rd 4.774 4.774 4.630 4th 3.926 3.926 3.807 5th 3.279 3.279 3.179 6th 2.790 2.790 2.706
Frame: Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension: Black and chrome leading link Forks
Rear Suspension: Hidden, horizontal-mounted, coil-over shock
Front Brakes: Single 292 mm disc 1 piston caliper
Rear Brakes: Single 292 mm disc 4 piston caliper
Front Tyre: D402F MT90B16 72H
Rear Tyre: D401 150/80B16 71H
Rake: 32°
Fork Angle: 40.3°
Trail: 160 mm / 6.3 in
Dimensions: Length 2400.4 mm / 94.5 in Width 995.0 mm / 39.2 in Height 1120.0 mm / 44.1 in
Wheelbase: 1639. mm / 64.5 in
Seat Height: Laden2 657.9 mm / 25.9 in Unladen 700 mm / 27.6 in
Ground Clearance: 125 mm / 4.9 in
Dry Weight: 321 kg / 708 lbs
Wet Weight: 337 kg / 741 lbs
Fuel Capacity: 18.9 Litres / 5.0 US gal
