Harley-Davidson Harley Davidson FLSTC/I Heritage Softail Classic (2005-06) technical specifications

Harley-Davidson Harley Davidson FLSTC/I Heritage Softail Classic technical specifications

Harley-Davidson Harley Davidson FLSTC/I Heritage Softail Classic is produced in 2005-06. Engine is Four stroke, 45° V-Twin, Twin Cam 88® vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1449 cc / 88.4 cu-in , produces power 67 hp / 48.8 kW @ 5200 rpm and 116.6 Nm / 86 lb-ft @ 3500rpm. Harley-Davidson Harley Davidson FLSTC/I Heritage Softail Classic weighs 317 kg / 699.0 lbs. Harley-Davidson Harley Davidson FLSTC/I Heritage Softail Classic has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FLSTC/I Heritage Softail Classic
Years: 2005-06
Engine: Four stroke, 45° V-Twin, Twin Cam 88® vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Capacity: 1449 cc / 88.4 cu-in
Bore x Stroke: 95.3 x 101.6 mm
Cooling System: Air cooled
Compression Ratio: 8.9:1
Lubrication: Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin on 10ì pressurized oil filter
Induction: Carburetion 40 mm constant velocity with enrichener and accelerator pump ESPFI 38 mm throttle bore electronic sequential port fuel injection
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starting: Electric
Max Power: 67 hp / 48.8 kW @ 5200 rpm
Max Torque: 116.6 Nm / 86 lb-ft @ 3500rpm
Transmission: 5 Speed
Final Drive: Belt
Gear Ratio: 1st 10.110 2nd 6.958 3rd 4.953 4th 3.862 5th 3.150
: Mild steel, rectangular section backbone
Front Suspension: 41.3 mm Telescopic forks, with “beer can” covers
Rear Suspension: Dual down-tubes Swing Arm Triangular “hard tail” style
Front Brakes: Single 292mm discs 4 piston calipers
Rear Brakes: Single 292mm disc 4 piston caliper
Front Tyre: 1D402F MT90B16 72H
Rear Tyre: D401 150/80B16 71H
Rake: 32°
Trail: 147.3 mm / 5.8 in
Dimensions: Length 2400.3 mm / 94.5 in.
Wheelbase: 1638.3 mm / 64.5 in
Seat Height: 645.2 mm / 25.4 in
Ground Clearance: 130 mm / 5.1 in
Dry Weight: 317 kg / 699.0 lbs
Wet Weight: 335 kg / 738.5 lbs
Fuel Capacity: 19 Litres / 5.0 US gal
