Harley-Davidson Harley Davidson FLHX Street Glide (2017-18) technical specifications

Harley-Davidson Harley Davidson FLHX Street Glide technical specifications

Harley-Davidson Harley Davidson FLHX Street Glide is produced in 2017-18. Engine is Four stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1746 cc / 107 cub in Harley-Davidson Harley Davidson FLHX Street Glide weighs 360 kg / 793 lbs. Harley-Davidson Harley Davidson FLHX Street Glide has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FLHX Street Glide
Years: 2017-18
Engine: Four stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Capacity: 1746 cc / 107 cub in
Bore x Stroke: 100 x 111 mm / 3.937 x 4.374 in
Cooling System: Air cooled
Compression Ratio: 10.0:1
Exhaust: Chrome, 2-1-2 dual exhaust with tapered mufflers
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Lubrication: Pressurized, dry-sump with oil cooler
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starting: Electric
Max Torque: 154 Nm / 113.6 lb-ft @ 3250 rpm
Clutch: Hydraulically actuated 9 plate wet, Assist & Slip
Transmission: 6 Speed
Final Drive: Belt
Primary Drive: Chain, 34/46 ratio
Gear Ratio: 1st 9.593 2nd 6.65 3rd 4.938 4th 4.0 5th 3.407 6th 2.875
Frame: Mild steel, square-section backbone with twin downtubes
Front Suspension: 41.3 mm telescopic, cartridge-style damping,
Front Wheel Travel: 117 mm / 4.6 in
Rear Suspension: Short, air-adjustable shock,
Rear Wheel Travel: 51 mm / 2.0 in
Front Brakes: Caliper Type 32 mm, 4-piston fixed
Rear Brakes: Caliper Type 32 mm, 4-piston fixed
Front Wheel: Enforcer Cast Aluminum
Rear Wheel: Enforcer Cast Aluminum
Front Tyre: 130/70B18 63H
Rear Tyre: 180/65B16 81H
Rake: 26°
Fork Angle: 29.2°
Trail: 173mm / 6.8 in
Dimensions: Length 2424 mm / 95.4 in
Seat Height: Laden 664 mm / 26.1 in Unladen 687 mm / 27 in
Ground Clearance: 122 mm / 4.8 in
Wheelbase: 1625 mm / 64 in
Gross Vehicle Weight Rating: 616.9 kg / 1360 lbs
Dry Weight: 360 kg / 793 lbs
Wet Weight: 376.4 kg / 830 lbs
Fuel Capacity: 22.7 Litres / US 6.0 gal
