Harley-Davidson Harley Davidson FLHTCU SE4 Electric Glide Ultra Classic CVO (2009) technical specifications

Harley-Davidson Harley Davidson FLHTCU SE4 Electric Glide Ultra Classic CVO is produced in 2009. Engine is Four stroke, Twin Cam 110™ with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, displacement 1802 cc / 109.96 cub in. Harley-Davidson Harley Davidson FLHTCU SE4 Electric Glide Ultra Classic CVO wet weight is 423.2 kg / 933 lbs. Harley-Davidson Harley Davidson FLHTCU SE4 Electric Glide Ultra Classic CVO has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson FLHTCU SE4 Electric Glide Ultra Classic CVO
Years:	2009
Engine:	Four stroke, Twin Cam 110™ with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Capacity:	1802 cc / 109.96 cub in.
Bore x Stroke:	101.6 x 111.1 mm
Cooling System:	Air/Liquid cooled,
Compression Ratio:	9.2:1
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	156 Nm / 15.9 kgf-m / 115 ft. lbs @ 3750 rpm
Clutch:	Multi-plate, wet
Transmissione:	6 Speed
Final Drive:	Belt
Gear Ratio:	1st 9.312 9.312 9.030 / 2nd 6.421 6.421 6.226 / 3rd 4.774 4.774 / 4.630 / 4th 3.926 3.926 3.807 / 5th 3.279 3.279 3.179 / 6th 2.790 2.790 2.706
Frame:	Mild steel, sqaure-section backbone with twin downtubes
Front Suspension:	41.3 mm telescopic forks,
Front Wheel Travel:	116 mm /
Rear Suspension:	Swing Arm Mild steel, rectangular tube sections, stamped junctions; MIG welded, Lowered, air-adjustable,
Front Brakes:	2x 300mm discs 4 piston calipers, ABS Standard
Rear Brakes:	Single 300mm disc 4 piston caliper, ABS Standard
Front Tyre:	D408 130/80B17 65H
Rear Tyre:	D407 180/65B16 81H
Trail:	170 mm / 6.6 in
Dimensions:	Length 2504 mm / 98.6 in. Width 965 mm / 38 in. Height 1549 mm / 61 in
Wheelbase:	1613 mm / 63.5 in
Seat Height:	Laden2 706 mm / 27.8 in Unladen 757 mm / 29.8 in
Wet Weight:	423.2 kg / 933 lbs
Fuel Capacity:	22.7 Litres / 6.0 US gal
