Harley-Davidson Harley Davidson FLHRC Road King Classic (2012-13) technical specifications
Harley-Davidson Harley Davidson FLHRC Road King Classic is produced in 2012-13. Engine is Four stroke, V-Twin, 'Twin Cam 103 with integrated oil cooler', displacement 1690 cc / 103.1 cub in. Harley-Davidson Harley Davidson FLHRC Road King Classic weighs 355.6 kg / 783 lbs. Harley-Davidson Harley Davidson FLHRC Road King Classic has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLHRC Road King Classic |
| Years: | 2012-13 |
| Engine: | Four stroke, V-Twin, 'Twin Cam 103 with integrated oil cooler' |
| Capacity: | 1690 cc / 103.1 cub in. |
| Bore x Stroke: | 98.4 x 111.1 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.7:1 |
| Exhaust: | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starring: | Electric |
| Max Torque: | 138 Nm / 14.1 kgf-m /102 ft/lb @ 3500 rpm |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Primary Drive: | Chain, 34/46 ratio |
| Gear Ratio: | 1st 9.593 / 2nd 6.65 / 3rd 4.938 / 4th 4.0 / 5th 3.407 / 6th 2.875 |
| Frame: | Mild steel, square-section backbone with twin downtubes |
| Lean Angle, Left: | 31º |
| Lean Angle, Right: | 33º |
| Front Suspension: | 41.3 mm telescopic, cartridge-style damping |
| Rear Suspension: | Short, air-adjustable shock |
| Front Brakes: | 2x 292mm disc 4 piston caliper |
| Rear Brakes: | Single 292mm disc 4 piston caliper |
| Front Tyre: | 130/90B16 67H |
| Rear Tyre: | 180/65B16 81H |
| Trail: | 170 mm / 6.7 in |
| Dimensions: | Length 2392 mm / 94.2 in Width 949.96 mm / 37.4 in Height 1399.54 mm / 55.1 in |
| Wheelbase: | 1612 mm / 63.5 in |
| Seat Height: | Laden2 678.mm / 26.7 in Unladen 714 mm / 28.1 in |
| Dry Weight: | 355.6 kg / 783 lbs |
| Wet Weight: | 368 kg / 811 lbs |
| Fuel Capacity: | 22.7 Litres / 6.0 US gal |
