Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO (2014) technical specifications

Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO technical specifications

Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO is produced in 2014. Engine is Four stroke, 45° V-Twin, Twin Cam 110 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1802 cc / 110 cu-in Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO weighs 354 kg / 779 lbs. Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson FLHR-SE5 Road King CVO
Years: 2014
Engine: Four stroke, 45° V-Twin, Twin Cam 110 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Capacity: 1802 cc / 110 cu-in
Bore x Stroke: 101.6 x 111.1 mm
Cooling System: Air cooled
Lubrication: Pressurized, dry-sump
Compression Ratio: 9.7:1
Exhaust: Chrome, 2-1-2 dual exhaust with tapered mufflers
Induction: Electronic Sequential Port Fuel Injection (ESPFI)
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starring: Electric
Max Torque: 156 Nm / 115 lb-ft @ 3000 rpm
Transmission: 6 Speed
Final Drive: Belt
Primary Drive: Chain, 34/46 ratio
Gear Ratio: 1st 9.593 2nd 6.65 3rd 4.938 4th 4.0 5th 3.407 6th 2.875
Frame: Mild steel, square-section backbone with twin downtubes
Front Suspension: 41.3 mm telescopic, cartridge-style damping
Rear Suspension: Short, air-adjustable shock
Front Brakes: 2x 292mm disc 4 piston caliper
Rear Brakes: Single 292mm disc 4 piston caliper
Wheels: Optional Style Type Tubeless Chrome Aluminum Profile Laced
Front Wheel: Black, 10-Spoke Cast Aluminum
Rear Wheel: Black, 10-Spoke Cast Aluminum
Front Tyre: 130/80B17 65H
Rear Tyre: 180/65B16 81H
Rake: 26°
Trail: 170 mm / 6.7 in
Dimensions: Length 2465 mm / 96.5 in
Wheelbase: 1625 mm / 64 in
Seat Height: Laden 673 mm / 26.5 in Unladen 711 mm / 28.0 in.
Gross Vehicle Weight Rating: 16.9 kg / 1360 lbs
Dry Weight: 354 kg / 779 lbs
Wet Weight: 371 kg / 814 lbs
Ground Clearance: 135 mm / 5.3 in
Oil Capacity: 3.3 Litres / 0.87 US gal
Fuel Capacity: 22.7 Litres / 6.0 gal
