Harley-Davidson Harley Davidson CVO Road Glide (2019) technical specifications

Harley-Davidson Harley Davidson CVO Road Glide technical specifications

Harley-Davidson Harley Davidson CVO Road Glide is produced in 2019. Engine is Four stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1923 cc / 117 cu-in Harley-Davidson Harley Davidson CVO Road Glide weighs 385 kg / 848.7 lbs. Harley-Davidson Harley Davidson CVO Road Glide has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson CVO Road Glide
Years: 2019
Engine: Four stroke, V-Twin, Milwaukee-Eight 117, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Capacity: 1923 cc / 117 cu-in
Bore x Stroke: 103.5 X 114.3 mm
Cooling System: Air cooled
Compression Ratio: 10.2:1
Exhaust: Dual, with crossover
Induction: Electronic Sequential Port Fuel Injection
Lubrication: Pressurized, dry-sump with oil cooler
Ignition: Single-fire, non-wasted, map-controlled spark ignition
Starting: Electric
Max Torque: 169 Nm / 124.6 lb-ft @ 3500 rpm
Transmission: 6 Speed
Primary Drive: Chain, 34/46 ratio
Final Drive: Belt
Gear Ratio: 1st 9.593 2nd 6.65 3rd 4.938 4th 4 5th 3.407 6th 2.875
Lean Angle, Left: 33.9º
Lean Angle, Right: 33.7º
Front Suspension: Showa dual bending valve front suspension
Rear Suspension: Emulsion rear suspension with hand-adjustable pre-load
Front Brakes: Caliper Type 32 mm, 4-piston fixed
Rear Brakes: Caliper Type 32 mm, 4-piston fixed
Front Wheel: Gloss Black and Contrast Chrome Knockout
Rear Wheel: Gloss Black and Contrast Chrome Knockout
Wheels Optional: Gloss Black and Contrast Black Anodize Knockout or Gunship Gray and Contrast Black Anodize Knockout
Front Tyre: 130/60B21 M/C63H
Rear Tyre: 180/55B18 M/C80H
Rake: 26°
Trail: 173 mm / 6.8 in
Dimensions: Length 2460 mm / 96.8 in
Wheelbase: 1625 mm / 64.0 in
Seat Height: 680 mm / 26.7 in
Ground Clearance: 125 mm / 4.9 in
Dry Weight: 385 kg / 848.7 lbs
Wet Weight: 401 kg / 884 lbs
Oil Capacity: 4.7 Litres / US 5 qts
Fuel Capacity: 22.7 Litres / US 6.0 gal
