Ducati Panigale V2 (2020) technical specifications

Ducati Panigale V2 technical specifications

Ducati Panigale V2 is produced in 2020. Engine is Four stroke, 90° “L” twin cylinder, DOHC, Desmodromic 4 valves per cylinder., displacement 955 cc / 58.3 cu in , produces power 114 kW / 155 hp @ 10750 rpm and 104 Nm / 76.7 lb-ft @ 9000 rpm. Ducati Panigale V2 weighs 176 kg / 388 lbs. Ducati Panigale V2 has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: Panigale V2
Years: 2020
Engine: Four stroke, 90° “L” twin cylinder, DOHC, Desmodromic 4 valves per cylinder.
Capacity: 955 cc / 58.3 cu in
Bore x Stroke: 100 x 60.8 mm
Compression Ratio: 12.5:1
Cooling System: Liquid cooled
Induction: Fuel Injection Electronic fuel injection system. Twin injectors per cylinder. Full rideby-wire elliptical throttle bodies
Exhaust: 2-1-2-1 system, with 2 catalytic converters and 2 lambda probes
Emission: Euro 5
Ignition: Electronic
Starting: Electric
Max Power: 114 kW / 155 hp @ 10750 rpm
Max Torque: 104 Nm / 76.7 lb-ft @ 9000 rpm
Clutch: Hydraulically controlled slipper and self-servo wet multiplate clutch
Transmission: 6 Speed with Ducati Quick Shift (DQS) up/down EVO 2
Final Drive: Chain; Front sprocket 15; Rear sprocket 43
Primary Drive: Straight cut gears; Ratio 1.77:1
Gear Ratio: 1st 37/15 2nd 30/16 3rd 27/18 4th 25/20 5th 24/22 6th 23/24
Frame: Monocoque Aluminium
Front Suspension: Fully adjustable Showa BPF fork. 43 mm chromed inner tubes
Front Wheel Travel: 120 mm / 4.72 in
Rear Suspension: Fully adjustable Sachs unit. Aluminum single-sided swingarm
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc M4.32 4-piston callipers with Cornering ABS EVO
Rear Brakes: Single 245 mm disc, 2-piston calliper with Cornering ABS EVO
Front Wheel: 5-spokes light alloy 3.50″ x 17
Rear Wheel: 5-spokes light alloy 5,50” x 17
Front Tyre: 120/70 ZR17 Pirelli Diablo Rosso Corsa II
Rear Tyre: 180/60 ZR17 Pirelli Diablo Rosso Corsa II
Display: Digital unit with 4,3″ TFT colour display
Rake: 24º
Trail: 94 mm / 3.8 in
Wheelbase: 1436 mm / 56,5 in
Seat Height: 840 mm / 33.1 in
Dry Weight: 176 kg / 388 lbs
Wet Weight: 200 kg / 441 lbs
Fuel Capacity: 17 Litres / 4.5 US gal / 3.7 Imp gal
