Ducati Multistrada V4S Grand Tour (2024) technical specifications

Ducati Multistrada V4S Grand Tour is produced in 2024. Engine is Four stroke, 90? Granturismo V 4, counter rotating crankshaft, 4 valves per cylinder, Twin Pulse firing order, displacement 1158 cc / 71 cu-in , produces power 125 kW / 170 hp @ 10500 rpm and 125 Nm / 92 lb-ft @ 8750 rpm. Ducati Multistrada V4S Grand Tour weighs 218 kg / 481 lbs. Ducati Multistrada V4S Grand Tour has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Multistrada V4S Grand Tour
Years:	2024
Engine:	Four stroke, 90? Granturismo V 4, counter rotating crankshaft, 4 valves per cylinder, Twin Pulse firing order
Capacity:	1158 cc / 71 cu-in
Bore x Stroke:	83 x 53.5 mm
Compression Ratio:	14.0:1
Cooling System:	Liquid cooled
Exhaust:	Stainless steel muffler, double catalytic converter and 4 lambda probes
Emission:	Euro 5
Induction:	Electronic fuel injection system, ?eq 46 mm elliptical throttle bodies with Ride-by-Wire system
Starting:	Electric
Max Power:	125 kW / 170 hp @ 10500 rpm
Max Torque:	125 Nm / 92 lb-ft @ 8750 rpm
Clutch:	Multiplate wet clutch with hydraulic control, self-servo action on drive, slipper action on over-run
Transmission:	6-speed gearbox with Ducati Quick Shift (DQS) Up & Down System
Final Drive:	Chain, front sprocket z16, rear sprocket z42
Gear Ratios:	1st 40/13, 2nd 36/16, 3rd 34/19, 4th 31/21, 5th 23/29, 6th 25/27
Primary Drive:	Straight cut gears, ratio 1.8:1
Frame:	Aluminum monocoque frame
Front Suspension:	50 mm fully adjustable USD fork, electronic compression and rebound damping adjustment with Ducati Skyhook Suspension
Front Wheel Travel:	170 mm / 6.7 in
Rear Suspension:	Fully adjustable monoshock, electronic adjustment with Ducati Skyhook Suspension, aluminum double-sided swingarm
Rear Wheel Travel:	180 mm / 7.1 in
Front Brakes:	2x 330mm semi-floating discs, radially mounted Brembo M50 Stylema monobloc 4-piston 2-pad calipers, radial master cylinder
Rear Brakes:	Single 265mm disc, Brembo 2-piston floating caliper
ABS System:	Standard Cornering ABS
Wheels:	Light alloy cast (Spoked optional)
Front Rim:	3 x 19 in
Rear Rim:	4.5 x 17 in
Front Tyre:	120/70 ZR 19 Pirelli Scorpion Trail II
Rear Tyre:	170/60 ZR 17 Pirelli Scorpion Trail II
Rake:	24.5?
Trail:	100.6 mm / 4.0 in
Wheelbase:	1566 mm / 61.7 in
Seat Height:	790 mm - 875 mm / 31.1 in - 34.4 in
Ground Clearance:	220 mm / 8.6 in
Dry Weight:	218 kg / 481 lbs
Wet Weight:	TBC
Fuel Capacity:	22 Litres / 5.8 US gal
Instrumentation:	6.5 in TFT color display with Ducati Connect and full-map navigation system
Safety Equipment:	Riding Modes, Power Modes, ABS Cornering, Ducati Traction Control, Ducati Wheelie Control, Daytime Running Light, Ducati Cornering Light, Ducati Brake Light, Vehicle Hold Control, Radar system (ACC + BSD)
Standard Equipment:	Ducati Skyhook Suspension, Ducati Quick Shift, Cruise control, Hands-free, Backlit handlebar switches, 6.5 in TFT color display with Ducati Connect and full-map navigation system, Full LED headlight, Hands-free fuel tank cap, Auxiliary LED lights, Heated rider and passenger seat, Heated handgrips, Central stand, Plastic side panniers
