Ducati Multistrada V4 Rally (2026) technical specifications

Ducati Multistrada V4 Rally is produced in 2026. Engine is Four stroke, 90? Granturismo V 4, counter rotating crankshaft, 4 valves per cylinder, Twin Pulse firing order, displacement 1158 cc / 71 cu-in , produces power 170 hp / 125 kW @ 10750 rpm and 123.8 Nm / 91 lb-ft @ 9000 rpm. Ducati Multistrada V4 Rally has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Multistrada V4 Rally
Years:	2026
Engine:	Four stroke, 90? Granturismo V 4, counter rotating crankshaft, 4 valves per cylinder, Twin Pulse firing order
Capacity:	1158 cc / 71 cu-in
Bore x Stroke:	83 x 53.5 mm
Compression Ratio:	14.0:1
Cooling System:	Liquid cooled
Exhaust:	Stainless steel muffler, double catalytic converter and 6 lambda probes
Emission:	Euro 5+
Induction:	Electronic fuel injection system, ?eq 46 mm elliptical throttle bodies with Ride-by-Wire system
Starting:	Electric
Max Power:	170 hp / 125 kW @ 10750 rpm
Max Torque:	123.8 Nm / 91 lb-ft @ 9000 rpm
Clutch:	Multiplate wet clutch with hydraulic control, self-servo action on drive, slipper action on over-run
Transmission:	6-speed gearbox with Ducati Quick Shift (DQS) Up & Down System
Final Drive:	Chain, front sprocket Z16, rear sprocket Z42
Gear Ratios:	1st 40/13, 2nd 36/16, 3rd 34/19, 4th 31/21, 5th 29/23, 6th 27/25
Primary Drive:	Straight cut gears, ratio 1.8:1
Frame:	Aluminum monocoque frame
Front Suspension:	50 mm Marzocchi fully adjustable USD fork, electronic compression and rebound damping adjustment with Adaptive Ducati Skyhook Suspension EVO (DSS), integrated stroke sensor
Front Wheel Travel:	170 mm / 6.7 in
Rear Suspension:	Fully adjustable monoshock, electronic adjustment with Ducati Skyhook Suspension, automatic fast lowering device between 6 mph and 30 mph, aluminum double-sided swingarm
Rear Wheel Travel:	180 mm / 7.1 in
Front Brakes:	V4: 2 x 320mm semi-floating discs, radially mounted Brembo M50 Stylema monobloc 4-piston 2-pad calipers, radial master cylinder V4S: 2 x 330mm semi-floating discs, radially mounted Brembo M50 Stylema monobloc 4-piston 2-pad calipers, radial master cylinder
Rear Brakes:	Single 280mm disc, Brembo 2-piston floating caliper
ABS System:	Standard Cornering ABS
Wheels:	Light alloy cast (Spoked optional)
Front Rim:	3 x 19 in Spoked
Rear Rim:	4.5 x 17 in Spoked
Front Tyre:	120/70 R 19 Pirelli Scorpion Trail II
Rear Tyre:	170/60 R 17 Pirelli Scorpion Trail II
Rake:	24.7?
Trail:	105 mm / 4.1 in
Wheelbase:	1572 mm / 61.9 in
Ground Clearance:	220 mm / 8.6 in
Seat Height:	Adjustable 870 - 890 mm / 34.3 - 35.0 in 885 mm - 905 mm / 34.9 in - 35.6 in - with high seat accessory 855 mm - 875 mm / 33.7 in - 34.5 in - with low seat #1 accessory 825 mm - 845 mm / 32.5 in - 33.3 in - with low seat #2 accessory 805 mm - 825 mm / 31.7 in - 32.5 in - with low seat #2 + low suspension kit accessory
Wet Weight (no fuel):	240 kg / 529 lbs
Fuel Capacity:	30 Litres / 7.9 US gal
Safety Equipment:	Riding modes, Ducati Traction Control, Engine Brake Control, Bosch Cornering ABS, Ducati Brake Light, Ducati Cornering Light, Radar System, Ducati Vehicle Observer, Ducati Wheelie Control, Auto Tyre Calibration Vehicle Hold Control.
Standard Equipment:	Ducati Quick Shift up/down 2.0, Ducati Skyhook Suspension, Coming Home, TFT colour display, Extended Cylinder Deactivation, Hands-free, Full LED lighting system, Full LED headlight, Daytime Running Light, Self cancelling turn indicators, Heated grips, Minimum Preload, Full-map navigation system, 12V socket, USB port, Backlit handlebar switches, Tyre pressure monitoring system, Systema radar adaptive cruise control, Forward collosion warning, blind spot detection.
