Ducati Multistrada 1260 S Grand Tour (2020) technical specifications

Ducati Multistrada 1260 S Grand Tour technical specifications

Ducati Multistrada 1260 S Grand Tour is produced in 2020. Engine is Four stroke, 90° “L” twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder, displacement 1262 cc / 77.0 cu-in , produces power 158 hp / 116 kW @ 9500 rpm and 129 Nm / 95 lb-ft @ 7500 rpm. Ducati Multistrada 1260 S Grand Tour weighs 215 kg / 474 lbs. Ducati Multistrada 1260 S Grand Tour has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: Multistrada 1260 S Grand Tour
Years: 2020
Engine: Four stroke, 90° “L” twin cylinders,Testastretta DVT with Desmodromic Variable Timing, DOHC, 4 valves per cylinder
Capacity: 1262 cc / 77.0 cu-in
Bore x Stroke: 106 x 71.5 mm
Cooling System: Liquid cooled
Compression Ratio: 13.0:1
Lubrication: Wet sump
Exhaust: Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes
Induction: Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm
Ignition: Marelli electronic
Starting: Electric
Max Power: 158 hp / 116 kW @ 9500 rpm
Max Torque: 129 Nm / 95 lb-ft @ 7500 rpm
Clutch: Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run
Transmission: 6 speed with Ducati Quick Shift up/down (DQS)
Final Drive: Chain, Front sprocket Z15, Rear sprocket Z40
Primary Drive: Straight cut gears, Ratio 1.84:1
Gear Ratio: 1st 37/15 2nd 30/17 3rd 27/20 4th 24/22 5th 23/24 6th22/25
Frame: Tubular steel trellis frame
Front Suspension: 48 mm fully adjustable usd fork, electronic compression and rebound damping adjustment with Ducati Skyhook Suspension Evo (DSS)
Front Wheel Travel: 170 mm / 6.7 in
Rear Suspension: Fully adjustable unit, electronic compression and rebound damping adjustment, electronic spring pre-load adjustment with Ducati Skyhook Suspension Evo (DSS), aluminium single-sided swingarm
Rear Wheel Travel: 170 mm / 6.7 in
Front Brakes: 2x 330 mm semi-floating discs, radially mounted Brembo monobloc M50 Evo 4-piston callipers, radial master cylinder, Cornering ABS
Rear Brakes: Single 265 mm disc, 2-piston floating calliper, Cornering ABS
Front Wheel: 5-spoke Y-shape cast light alloy 3.50" x 17"
Rear Wheel: 5-spoke Y-shaped cast light alloy 6.0" x 17"
Front Tyre: 120/70 ZR17 Pirelli Scopion Trail II
Rear Tyre: 190/55 ZR17 Pirelli Scorpion Trail II
Rake: 25°
Trail: 111 mm / 4.4 in
Wheelbase: 1585 mm / 62.4 in
Seat Height: Adjustable 825 mm / 32.5 in - 845 mm / 33.3 in
Dry Weight: 215 kg / 474 lbs
Wet Weight: 238 kg / 525 lbs
Fuel Capacity: 20 Litres / 5.3 US gal
