Ducati 250 Mark 3D Desmo (1970) technical specifications

Ducati 250 Mark 3D Desmo technical specifications

Ducati 250 Mark 3D Desmo is produced in 1970. Engine is Four stroke, single cylinder, Desmo SOHC, bevel gear driven, displacement 248.6 cc / 15.2 cu in , produces power 16.4 kW / 22 hp @ 7500 rpm. Ducati 250 Mark 3D Desmo top speed is 150 km/h / 93 mph. Ducati 250 Mark 3D Desmo weighs 127 kg / 280 lbs. Ducati 250 Mark 3D Desmo has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: 250 Mark 3D Desmo
Years: 1970
Engine: Four stroke, single cylinder, Desmo SOHC, bevel gear driven
Capacity: 248.6 cc / 15.2 cu in
Bore x Stroke: 74 x 57.8 mm
Compression Ratio: 10.0:1
Cooling System: Air cooled
Induction: Dell'Orto SS1 29D carburetor
Ignition: Coil, 6V 30W generator (later 6V 70 W)
Battery: SAFA 3L3 13.5 Ah
Spark Plug: Marelli CW260N / Lodge 2HN
Starting: Kick
Max Power: 16.4 kW / 22 hp @ 7500 rpm
Primary Drive Ratio: 2.500:1
Transmission: 5 Speed
Gear Ratios: 1st 2.46 / 2nd 1.73 / 3rd 1.35 / 4th 1.10 / 5th 0.97:1
Final Drive: Chain
Final Drive Ratio: 2.812:1
Front Suspension: Hydraulic fork, Ducati 31.5 mm
Rear Suspension: Swingarm, Marzocchi dual shocks, 3-way adjustable
Front Brakes: 180mm Drum
Rear Brakes: 160mm Drum
Front Tyre: 2.75-18
Rear Tyre: 3.00-18
Dimensions: Length: 2000 mm / 78.7 in Width: 600 mm / 23.6 in Height: 940 mm / 37.0 in
Wheelbase: 1360 mm / 53.5 in
Seat Height: 735 mm / 28.9 in
Dry Weight: 127 kg / 280 lbs
Fuel Capacity: 13 L / 3.4 US gal / 2.9 Imp gal
Standing ¼ Mile: 18.9 sec
Top Speed: 150 km/h / 93 mph
