BMW R nineT Pure (2021) technical specifications

BMW R nineT Pure technical specifications

BMW R nineT Pure is produced in 2021. Engine is Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counterbalancer shaft., displacement 1170 cc / 71.4 cub in , produces power 80 kW /109 hp @ 7250 rpm and 116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm. BMW R nineT Pure wet weight is 219 kg / 483 lbs. BMW R nineT Pure has 7 photos.

Technical specifications

+ Add to 'Compare list'
Model: R nineT Pure
Years: 2021
Engine: Four stroke, two cylinder horizontally opposed Boxer, two camshafts and four radially aligned valves per cylinder, central counterbalancer shaft.
Capacity: 1170 cc / 71.4 cub in
Bore x Stroke: 101 x 73 mm
Cooling System: Air/Oil cooled
Compression Ratio: 12.0:1
Lubrication: Wet sump
Induction: Electronic intake pipe injection / digital engine management with overrun cutoff, twin-spark ignition
Emission Control: Controlled 3-way catalytic converter, exhaust emission standards EU-5
Fuel: Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)
Alternator: Three-phase alternator with 720 Watt nominal power
Battery: 12 V / 12 Ah, maintenance-free
Starting: Electric
Max Power: 80 kW /109 hp @ 7250 rpm
Max Torque: 116 Nm / 11.8 kgf-m / 85.6 lb-ft @ 6000 rpm
Clutch: Single dry plate clutch, hydraulically operated
Transmission: 6-speed, claw-shifted transmission with helical-cut splines
Final Drive: Shaft
Frame: Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front Suspension: 46 mm upside-down telescopic forks
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by hook wrench, adjustable rebound-stage damping
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: 2 x 320 mm discs, 4 piston calipers
Rear Brakes: Single 265 mm disc, 2 piston floating caliper
ABS: BMW Motorrad ABS Pro
Wheels: Cast
Front Rim: 3.50 x 17
Rear Rim: 5.50 x 17
Front Tyre: 120/70 - ZR17
Rear Tyre: 180/55 - ZR17
Castor: 105 mm / 4.1 in
Steering Head Angle: 63.4 °
Dimensions: Length 2105 mm / 82.9 in Width 865 mm / 34.0 in Height 1240 mm / 48.8 in
Wheelbase: 1493 mm / 58.7 in
Seat Height: 805 mm / 31.7 in
Wet Weight: 219 kg / 483 lbs
Fuel Capacity: 17 Litres / 4.5 US gal
