BMW R 1200RT LC (2014) technical specifications

BMW R 1200RT LC is produced in 2014. Engine is Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder, displacement 1170, 71.4 co in , produces power 92 kW / 125 hp @ 7750 rpm and 125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm. BMW R 1200RT LC weighs 221 kg / 487 lbs. BMW R 1200RT LC has 12 photos.

Technical specifications

+ Add to 'Compare list'

Model:	R 1200RT LC
Years:	2014
Engine:	Four stroke, two cylinder horizontally opposed Boxer, DOHC, 4 valves per cylinder
Capacity:	1170, 71.4 co in
Intake / outlet:	40 mm / 34 mm
Bore x Stroke:	101 x 73 mm
Cooling System:	Liquid cooled
Compression Ratio:	12.5:1
Fuel:	Premium unleaded (95 RON)
Induction:	Throttle valve mm 52 Carburetion BMS-X Emission control Closed-loop 3-way catalytic converter
Exhaust management:	Fully-controlled three-way catalytic converter
Ignition:	Digital engine management
Starting:	Electric
Throttle valve:	52 mm
Alternator:	620 W
Battery:	Ah 12V/12 Ah maintenance-free
Headlight:	H7W / LED (SA)
Max Power:	92 kW / 125 hp @ 7750 rpm
Max Torque:	125 Nm / 12.7 kgf-m / 92 lb-ft @ 6500 rpm
Clutch:	Single disc dry clutch, hydraulically actuated
Transmission:	6 Speed
Final Drive:	Shaft
Primary Ratio:	1.65
Gear Ratio:	1st 2.438 / 2nd 1.714 / 3rd 1.296 / 4th 1.059 / 5th 0.943 / 6th 0.848:1
Frame:	Tubular steel frame, engine load-bearing
Front Suspension:	BMW Telelever
Front wheel Travel:	120 mm / 4.7 in
Rear Suspension:	BMW EVO Paralever
Rear wheel Travel:	136 mm / 5.4 in
Front Brakes:	2 x 320mm Discs, 4 piston callipers
Rear Brakes:	Single 276mm disc, 2 piston caliper
ABS:	BMW Motorrad Inteqral ABS (standard, part inteqral))
Wheelss:	Cast aluminium wheels
Wheel Front:	3.5o x 17
Rear Wheel:	5.50 x 17
Front Tyre:	120/70 ZR17
Rear Tyre:	180/60 ZR17
Steering Head Angle:	63.6°
Wheel Castor:	116 mm / 4.56"
Dimensions:	Length 2222 mm / 87.5 in Width 983 mm / 38.7 in Height 1417 mm / 55.7 in
Wheelbase:	1485 mm / 58.5 in
Seat Height:	805 mm / 31.5 in - 825 mm / 32.5 in (SA: 830mm / 850mm or 760mm / 780mm)
Dry Weight:	221 kg / 487 lbs
Wet Weight:	274 kg / 604 lbs
Permitted Total Weight:	495 kg / 1091 lbs
Fuel Capacity:	25 Litres / 6.6 US gal
Reserve:	4 Litres / 1 US gal
