BMW F 800GS (2013) technical specifications

BMW F 800GS technical specifications

BMW F 800GS is produced in 2013. Engine is Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder, displacement 798 cc / 47.7 cub. in. , produces power 62.5 kW / 85 hp @ 7500 rpm and 80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm. BMW F 800GS top speed is 199.0 km/h / 124 mph. BMW F 800GS weighs 177.8 kg / 392 lbs. BMW F 800GS has 6 photos.

Technical specifications

+ Add to 'Compare list'
Model: F 800GS
Years: 2013
Engine: Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity: 798 cc / 47.7 cub. in.
Bore x Stroke: 82 x 75.8 mm
Compression Ratio: 12.0:1
Cooling: Liquid cooled
Induction: Electronic intake injection, ∅45mm throttle bodies
Ignition: Knock control and oxygen sensors.
Starting: Electric
Max Power: 62.5 kW / 85 hp @ 7500 rpm
Max Torque: 80 Nm / 8.2 kgf-m / 59 lb-ft @ 5750 rpm
Clutch: Multiplate-plate in oil bath
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st 2.46 / 2nd 1.75 / 3rd 1.38 / 4th 1.17 / 5th 1.04 / 6th 0.96
Final Drive Ratio: 1:2.6
Frame: Tubular frame in steal partly carrying the engine
Rake: 26°
Trail: 117 mm / 9.1 in.
Front Suspension: ∅43mm Marzocchi upside down forks
Front Wheel Travel: 230 mm / 9.1 in.
Rear Suspension: Double strut swing arm aluminium coast in one piece
Rear Wheel Travel: 215 mm / 8.5 in.
Front Brakes: 2 x ∅300mm discs, 4 piston calipers, ABS
Rear Brakes: Single ∅265mm disc, 2 piston caliper, ABS
Wheels: Wire spoke
Rim Front: 2.15 x 21"
Rim Rear: 4.25 x 17"
Front Tyre: 90/90 - 21 54V
Rear Tyre: 150/70 - 17 69V
Dimensions: Length 2320 mm / 91.3 in Width 945 mm / 37.2 in (incl. mirrors) Height 1350 mm / 53.1 in (excl. mirrors)
Seat Height: 880 mm - 820 mm / 34.6 in. - 32.3 in.
Wheel Base: 1577 mm / 62.1 in
Dry Weight: 177.8 kg / 392 lbs
Wet Weight: 207 kg / 456 lbs
Fuel Capacity: 16 Litres / 4.2 US gal.
Consumption Average: 5.1 l/100km / 19.6 km/l / 45.9 US mpg
Average Tank Distance: 312 km / 194 miles
Standing ¼ Mile: 12.5 sec
Top Speed: 199.0 km/h / 124 mph
