BMW C 400X (2018-19) technical specifications

BMW C 400X technical specifications

BMW C 400X is produced in 2018-19. Engine is Four stroke, Single cylinder, SOHC, 4 Valves, with rocker arm., displacement 350 cc / 21.3 cub in. , produces power 25.3 kW / 34 hp @ 7500 rpm and 34.3 Nm / 25.8 lb-ft @ 6000 rpm. BMW C 400X wet weight is 204 kg / 450 lbs. BMW C 400X has 10 photos.

Technical specifications

+ Add to 'Compare list'
Model: C 400X
Years: 2018-19
Engine: Four stroke, Single cylinder, SOHC, 4 Valves, with rocker arm.
Capacity: 350 cc / 21.3 cub in.
Bore x Stroke: 80 x 69.6 mm
Compression Ratio: 11.5:1
Cooling: Liquid cooled
Induction: Fuel injection, BMS-E2 40mm throttle valve diameter
Fuel: Regular lead free (95 RON)
Starting: Electric, 500 kW
Alternator: 316W
Battery: 12/9 V/Ah
Max Power: 25.3 kW / 34 hp @ 7500 rpm
Max Torque: 34.3 Nm / 25.8 lb-ft @ 6000 rpm
Clutch: Centrifugal clutch
Transmission: Continuously variable CVT belt transmission
Final Drive: Gear reduction cog wheel pairing
Frame: Tubular spaceframe
Front Suspension: 35mm Telescopic forks.
Front Wheel Travel: 110 mm / 4.3 in
Rear Suspension: Aluminum double-sided swing arm, double spring strut, adjustable spring preload
Rear Wheel Travel: 112 mm / 4.4 in
Front Brakes: 2x 265mm Rigid discs 4 piston caliper.
Rear Brakes: Single 265mm disc 1 piston caliper.
ABS: BMW Motorrad ABS
Wheels: Die-cast aluminum wheels
Front Rim: 3.50 x 15
Rear Rim: 4.25 x 14
Front Tyre: 120/70 ZR15
Rear Tyre: 150/70 ZR14
Rake: 26.4°
Trail: 81.2 mm / 3.2 in
Dimensions: Length 2210 mm / 87 in Width 833 mm / 32.8 in
Wheel Base: 1564.5 mm / 61.6 in.
Seat Height: 775 mm / 30.5 in
Inside Leg Length: 1760 mm / 69.3 in
Wet Weight: 204 kg / 450 lbs
Fuel Capacity: 12.8 Litres / 3.4 US gal
