Aprilia RSV-4 APRC (2014) technical specifications

Aprilia RSV-4 APRC technical specifications

Aprilia RSV-4 APRC is produced in 2014. Engine is Four stroke, longitudinal 65° V four , DOHC, 4 valves per cylinder, displacement 999.6 cc / 61.0 cu-in , produces power 132 kW / 180 hp @ 12500 rpm and 115 Nm / 11.7 kgf-m / 84.8 lb-ft @ 10000 rpm. Aprilia RSV-4 APRC top speed is 291.2 km/h / 180.9 mph. Aprilia RSV-4 APRC weighs 182 kg / 401 lbs. Aprilia RSV-4 APRC has 4 photos.

Technical specifications

+ Add to 'Compare list'
Model: RSV-4 APRC
Years: 2014
Engine: Four stroke, longitudinal 65° V four , DOHC, 4 valves per cylinder
Capacity: 999.6 cc / 61.0 cu-in
Bore x Stroke: 78 x 52.3 mm
Cooling System: Liquid cooled
Compression Ratio: 13.0:1
Induction: Airbox with front dynamic air intakes. Variable length intake ducts controlled via ECU. 4 Weber-Marelli 48-mm throttle bodies with 8 injectors and latest generation Ride-by-Wire engine management. Choice of three different engine maps selectable by the rider with bike in motion: T (Track), S (Sport), R (Road) Magneti Marelli digital electronic ignition system integrated in engine control system, with one spark plug per cylinder and "stick-coil"-type coils
Ignition: Electronic digital ignition integrated in the fuel management system.
Starting: Electric
Exhaust: 4 into 2 into 1 layout, single oxygen sensor, lateral single silencer with engine control unit-controlled butterfly valve and integrated trivalent catalytic converter (Euro 3) Flywheel mounted 420W alternator with rare earth magnets
Lubrication: Wet sump. Two pumps (lubrication and cooling). Oil cooler.
Max Power: 132 kW / 180 hp @ 12500 rpm
Max Torque: 115 Nm / 11.7 kgf-m / 84.8 lb-ft @ 10000 rpm
Clutch: Cassette type
Transmission: 6 Speed
Final Drive: Chain
Gear Ratio: 1st: 39:15 (2.6) / 2nd: 33:16 (2,063) / 3rd: 34:20 (1.7) / 4th: 32:22 (1,455) / 5th: 34:26 (1,308) / 6th: 33:27 (1,222)
Primary drive: Straight cut gears and integrated flexible coupling, drive ratio: 73:44 (1,659) Secondary drive Chain: Drive ratio: 42:16 (2.625) Traction management APRC System (Aprilia Performance Ride Control), which includes Traction Control (ATC), Wheelie Control (AWC), Launch Control (ALC), all of which can be configured and deactivated independently.
Frame: Twin-spar adjustable aluminium frame, with castings and pressings. Adjustments: • headstock position and rake • engine height • swingarm pin height, Öhlins adjustable steering dumper
Front Suspension: Öhlins Racing upside-down fork, 43-mm stanchions (with Tin surface treatment). Low profile forged aluminium radial
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: Twin sided aluminium swingarm; mixed low thickness and sheet casting technology. Öhlins Racing monoshock with piggyback with completely adjustable: spring preload, wheelbase and hydraulic compression and rebound damping. APS progressive linkages.
Rear Wheel Travel: 130 mm / 5.1 in
Front Brakes: 2 x Ø320 mm diameter floating stainless steel disc with lightweight stainless steel rotor and aluminium flange with 6 pins. Brembo monobloc radial calipers with 4 x Ø34 mm opposite. Sintered pads. Radial pump and metal braided brake hose
Rear Brakes: Single Ø220 mm diameter disc, Brembo floating caliper with two Ø32 mm isolated pistons. Pump with integrated tank and metal braided hose
Front Tyre: 120/70 ZR17
Rear Tyre: 200/55 ZR 17 (alternative: 190/50 ZR 17; 190/55 ZR17)
Steering Angle: 24.5°
Trail: 105 mm / 4.1 in
Dimensions: Length: 2040 mm / 80.3 in Width: 735 mm / 28.9 in (at the handlebar) Height : 1120 mm / 44.0 in
Ground Clearance: 130 mm / 5.1 in
Seat Height: 845 mm / 33.2 in
Dry Weight: 182 kg / 401 lbs
Fuel Capacity: 17 Liters / 4.4 US gal
Fuel Reserve: 4 Liters / 1.1 US gal
Standing ¼ Mile: 10.5 sec
Top Speed: 291.2 km/h / 180.9 mph
