AJP PR3 125 Trail, Enduro (Pro), Supermoto (2009-14) technical specifications
AJP PR3 125 Trail, Enduro (Pro), Supermoto is produced in 2009-14. Engine is Single cylinder, 4-stroke, 2-valve, displacement 124 cc / 7.6 cub in , produces power 9.3 kW / 12.5 hp @ 8500 rpm and 8.5 Nm / 0.87 kgf-m / 6.3 ft lbs @ 8000 rpm. AJP PR3 125 Trail, Enduro (Pro), Supermoto weighs 100 kg / 220 lbs. AJP PR3 125 Trail, Enduro (Pro), Supermoto has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | PR3 125 Trail, Enduro (Pro), Supermoto |
| Years: | 2009-14 |
| Engine: | Single cylinder, 4-stroke, 2-valve |
| Capacity: | 124 cc / 7.6 cub in |
| Bore x Stroke: | 56.5 x 49.5 mm |
| Cooling System: | Air/oil cooled |
| Engine Oil: | NI i-Ride SAE 20WW-50 API SF or SG |
| Oil Capacity: | 1.0 L / 2.1 US pints |
| Exhaust: | 1-into-1 |
| Induction: | Walbro 30 mm carburetor |
| Spark Plug: | LG D8TC (Champion A8YC or NGK DR8ES) |
| Battery: | YTX5L-BS, 12V, 4Ah |
| Starting: | Electric + kick |
| Max Power: | 9.3 kW / 12.5 hp @ 8500 rpm |
| Max Torque: | 8.5 Nm / 0.87 kgf-m / 6.3 ft lbs @ 8000 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Chain |
| Frame: | Aluminium double beam and double steel cradle |
| Front Suspension: | Marzocchi USD 38 mm, multi-adjustable |
| Front Wheel Travel: | 240 mm / 9.5 in |
| Rear Suspension: | ZF Sachs – Progressive System with reservoir, multi adjustable |
| Rear Wheel Travel: | 280 mm / 11.0 in |
| Front Brakes: | Disc, 260 mm, double piston caliper |
| Rear Brakes: | Disc, 220 mm, single piston caliper |
| Wheels: | Steel with wire spokes |
| Front Tyre: | Trail: 2.75 - 19 Enduro (Pro): 70/100-19 Supermoto: 100/80-17 |
| Rear Tyre: | Trail: 3.25 - 17 Enduro (Pro): 100/100-17 Supermoto: 130/70-17 |
| Wheelbase: | 1320 mm / 52.0 in |
| Ground Clearance: | 305 mm / 12 in |
| Seat Height: | 840 mm / 33.1 in |
| Dry Weight: | 100 kg / 220 lbs |
| Fuel Capacity: | 7 L / 1.8 US gal |
