Yamaha YZF 1000 R1M (2016) technical specifications

Yamaha YZF 1000 R1M technical specifications

Yamaha YZF 1000 R1M is produced in 2016. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder., displacement 998 cc / 60.9 cu-in , produces power 147.1 kW / 200.0 hp @ 13500 rpm and 112.4 Nm / 11.5 kg-m @ 11500 rpm. Yamaha YZF 1000 R1M wet weight is 199 kg / 439 lbs. Yamaha YZF 1000 R1M has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: YZF 1000 R1M
Years: 2016
Engine: Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.
Capacity: 998 cc / 60.9 cu-in
Bore x Stroke: 79.0 x 50.9 mm
Compression Ratio: 13.0:1
Cooling System: Liquid cooled
Lubrication: Wet sump
Engine Management: YCC-T, YCC-I, PWR, TCS, LCS, LIF, SCS, QSS, CCU & SCU
Induction: Fuel Injection with YCC-T and YCC-I
Ignition: TCI: Transistor Controlled Ignition
Starting: Electric
Max Power: 147.1 kW / 200.0 hp @ 13500 rpm
Max Torque: 112.4 Nm / 11.5 kg-m @ 11500 rpm
Clutch: Wet, Multiple Disc
Transmission: 6-speed w/multiplate slipper clutch
Final Drive: "O" ring chain
Front Suspension: 43mm KYB® inverted fork; fully adjustable
Front Wheel Travel: 120 mm / 4.7 in
Rear Suspension: KYB® Single shock w/piggyback reservoir, 4-way adjustable
Rear Wheel Travel: 120 mm / 4.7 in
Front Brakes: 2x 320mm discs 4 piston calipers, UBS ABS
Rear Brakes: Single 220mm disc 1 piston caliper, UBS ABS
Front Tyre: 120/70 ZR17
Rear Tyre: 190/55 ZR17
Dimensions: Length 2054.8 mm / 80.9 in Width 690 mm / 27.2 in Height 1150 mm / 45.3 in
Wheelbase: 1419 mm / 55.9 in
Ground Clearance: 135mm / 5.3 in
Seat Height: 830 mm / 32.7 in
Wet Weight: 199 kg / 439 lbs
Fuel Capacity: 17 Liters / 4.5 US gal
